EL320.240-FA3 Operations Manual Page 22 of 25
Reliability
The display MTBF is to be greater than 50,000 hours at maximum luminance
and maximum input power with a 90% confidence level at 25°C.
Safety and EMI Performance
The display will not inhibit the end product from obtaining these certifications:
IEC 60101-1; UL60950; CSA 22.2 #950; FCC Part 15, Subpart J, Class B; EN55022
Class B.
Mechanical Characteristics
Mechanical Characteristics
Display External Dimensions
millimeters (inches)
width 150.3 (5.92)
height 104.8 (4.13)
depth 20.56 max (0.81)
Weight (typical) 198 g
Display Active Area
millimeters (inches)
width 99.15
(4.05)
height 74.36 (2.93)
diagonal 123.94 (4.88)
Pixel Size
millimeters (inches)
width 0.265
(0.010)
height 0.265 (0.010)
Pixel Pitch
millimeters (inches)
width 0.31
(0.012)
height 0.31 (0.012)
