- 9 -
. SPECIFICATIONS
MAIN UNIT
Model EY6903 EY6932
Capability
Screw
driving
Machine screw M3 - M5 M3 - M6
Wood screw ш 2.1 - ш 5.8 mm (5/64" - 15/64") ш 2.1 - ш 6.8 mm (5/64" - 17/64")
Masonry screw ш 4 - ш 6 mm (5/32" - 15/64")
Drilling
Mortar/Brick ш 3 - ш 10 mm (1/8” - 3/8”) ш 3 - ш 13 mm (1/8" - 1/2")
Wood ш 3 - ш 25 mm (1/8” - 63/64”) ш 3 - ш 36 mm (1/8" - 1-27/64")
Metal ш 1.5 - ш 13 mm (1/16" - 1/2")
Metal hole saw Max. ø 26 mm (1-1/64") Max. ø 34 mm (1-11/32")
Motor DC Motor 12 V DC Motor 15.6 V
No load speed
LOW 80 - 550/min (rpm)
HIGH 300 - 2000/min (rpm)
Blows rate per minute
LOW 1200 - 8250/min (bpm)
HIGH 4500 - 30000/min (bpm)
Chuck capacity ш 1.5 - ш 13 mm (1/16" - 1/2")
Maximum torque
LOW 17.8 Nm (182 kgf-cm or 158 in-lbs) 25.5 Nm (260 kgf-cm or 225 in-lbs)
HIGH 4.6 Nm (47 kgf-cm or 41 in-lbs) 5.9 Nm (60 kgf-cm or 52 in-lbs)
Blow strength 1.7 kN (173 kgf, 370 lbs.f)
Overall length 236 mm (9-5/16")
Weight (with battery pack) 2.2 kg (4.9 lbs) 2.4 kg (5.3 lbs)
BATTERY PACK
Model EY9200 EY9201 EY9230 EY9231
Storage battery Ni-MH Battery
Battery voltage 12 V DC (1.2 V × 10 cells) 15.6 V DC (1.2 V × 13 cells)
BATTERY CHARGER
Model EY0110
Electrical rating See the rating plate on the bottom of the charger.
Weight 0.78 kg (1.72 lbs)
Charging time
7.2V 9.6 V 12V 15.6V 18V 24V
1.2Ah
EY9065
EY9066
EY9080
EY9086
EY9001
EY9006
20min.
1.7Ah
EY9180
EY9182
EY9101
25min.
2.0Ah
EY9168 EY9106 EY9136 EY9117
30min. 30min. 60min.
3.0Ah
EY9200 EY9230 EY9210
45min. 90min.
3.5Ah
EY9201 EY9231 EY9251
55min. 65min.
Note: This chart may include models that are not available in your area.
Please refer to the catalogue.
