Panasonic AJ-D750P - Manual (Page 65)

Printed circuit board
Printed
circuit
board
Abbr.
name
Full name Function
F8 board SW1
ADDA1
Audio Input
Impedance SW
SW41 Audio Input
Impedance SW
H2 board SW101 Cue Input
CUE Impedance SW
This sets the CH1 audio input
impedance.
HIGH/600W
This sets the CH2 audio input
impedance.
HIGH/600W
This sets the CUE input impedance.
F4 board SW940 Component P B /P R This sets the component P B /P R
Output level output level when connecting with
selector the editor.
M II : M II level
BETA : -CAM level
Factory
setting
HIGH
HIGH
HIGH
BETA
- 65 -
