5” coaxial midrange drivers, 1” entry horn – PHL Audio X17 User Manual

Page 2

background image

6.35 x 0.8 FAST ON
Terminal

4 x Ø 5.3 Holes on Ш 172

Ш 162.5 max.

Ø 139 max.

Ø 146 max.

68.5 max.

8

+
Red dot

Ø

187.5 max.

(on angles)

Ø 25.4

76.2

Comp. driver
push holder

65

max

Locating hole Ø 6.5

1520

1530

6.5” Coaxial Midrange Drivers

1” Entry Horn

1520

1530

TYPICAL CHARACTERISTICS

Rated impedance

Z

8

16

Reference efficiency (1 W@1 m)

-

97

97

dB SPL

Usable frequency range

1

-

400–5000

400–5000

Hz

Power handling capacity

2

(AES)

-

250

250

W

Max Sound Pressure Level

3

SPLmax

118

118

dB SPL

Min. impedance modulus

Zmin

6.2 @ 750Hz

12.0 @ 700Hz

Voice-coil inductance

4

@ 1 kHz

Le1k

0.55

1.08

mH

@ 10 kHz

Le10k

0.31

0.62

mH

Bl product

Bl

11.0

15.8

N/A

Moving mass

Mms

0.0105

0.0105

Kg

THIELE-SMALL PARAMETERS : TYPICAL (QC LIMITS)

Resonance frequency

5

Fs

130 (±25)

130 (±25)

Hz

DC resistance

6

Re

5.5 (±0.5)

10.6 (±1.1)

Mechanical quality factor

Qms

4.0

4.0

1

Electrical quality factor

Qes

0.38

0.35

1

Total quality factor

Qts

0.35

0.33

1

Mechanical suspension compliance

Cms

145

145

10

-6

m/N

Effective piston area

Sd

0.0123

0.0123

m

2

Equivalent Cas air load

Vas

0.0035

0.0035

m

3

Max. linear excursion

Xmax

±1.0

±1.0

mm

Linear displacement volume

Vd

0.0123

0.0123

10

-3

m

3

Half-space efficiency

1.9

2.0

%

Unity load volume

Vas Qts

2

0.41

0.36

10

-3

m

3

ABSOLUTE MAXIMUM RATINGS

Short term max. input voltage

7

Vmax

90

125

V

Max. excursion before damage

Xdam

4.0

4.0

mm

Ambient operating temperature

–10 to +50

°C

Storage temperature

8

–20 to +70

°C

Environmental conditions

9

Outdoor

APPLICATION INFORMATION

Air volume occupied by the driver

10

0.64

0.64

10

-3

m

3

Speaker net mass

2.6

2.6

Kg

Recommended reflex box

Vb/Fb

3L / sealed

L / Hz

Electrical polarity

A positive voltage applied on the red terminal

produces forward cone motion.

SPECIFICATION NOTES

Note 1 : Allowing for energy response, excursion

capability, Power spectrum, and -3dB low
freq. roll-off for standard reflex tuning.

Note 2 : Established at 20°C ambient temp, according to

AES2-1984 standard using IEC268-1 simulated
programme signal and a 3 liter sealed test enclosure
with a 2nd order high-pass filter @ 800Hz.

Note 3: Established at 1m on axis of the loudspeaker mounted

in test enclosure, when driven at full AES Power
Handling Capacity, including 3dB of thermal
compression loss.

Note 4 : Measured at 20 mA in free air.

Note 5: Measured at 20 mA and 20°C ambient temp.

in free air conditions, after full run and rest.

Note 6 : Measured at 20°C ambient temp.

QC limits are ±10%

Note 7: Stated in RMS voltage according to IEC 268-5.

Note 8 : Includes shipping conditions.

The lower limit prevents from demagnetization.

Note 9: Our products are classified in three categories :

Indoor, Outdoor, and Outdoor

✚ for permanent

outdoor use or severe conditions.

Note 10 : Calculated for front mounting on to a 18 mm thick

board.

PHYSICAL CHARACTERISTICS
