41 206-4147
After verifying the STB Setup, set Installer
Menu item 028 CH. OVERIDE to 000.*
Commercial Mode Setup for Master STB1000 (Cont.)
DIGITAL
WXYZ
MONO STEREO SAP
19-3
Custom Text Label “WXYZ” created in
2-5-4 + MENU (Add Channel Label) Mode.
(Continued from previous page)
3. Run Auto Tuning (Channel Search).
a) Search for all available analog and digital channels: Go to the
Channel Menu, select the Auto Tuning option, and follow the on-
screen instructions.
b) Use the Channel Edit option in the Channel Menu to edit the
channel lineup, as necessary, to include free to guest channels
only.
• Add/delete channels per your system requirements. Note that
physical channel numbers are used to identify virtual channels.
Also, channel numbers cannot be higher than 255.
• Use the Channel Label option in the Channel Menu to add
familiar channel trademarks/logos such as ABC, CBS, NBC,
etc. to the Channel-Time on-screen display. Identifi able labels
(logos) should enable the end user to readily know what
common networks are available. (You can add the channel
labels in this step, or you can add channel logos or labels for
channels without icons in step 5.)
4. Transfer the STB1000 Setup to the internal STB Controller
(PTC): 2-5-5 + MENU Mode
After the STB channel lineup has been edited and channel labels
added, enter the Installer Menu. Once in the Installer Menu, press
2-5-5 + MENU on the Installer Remote to initiate the transfer of the
Master STB Setup to the PTC. The STB exits the Installer Menu and
then tunes through the channels in the channel lineup during the
transfer. When the transfer is complete, the STB tunes back to the
channel that was tuned before the transfer began.
Note: The maximum number of active channels that can be trans-
ferred is 141. Total channels numbering more than 141 will result in
erratic STB operation.
5. Add Custom Channel and Aux Source Labels for Analog
Channels: 2-5-4 + MENU Mode
Enter the Installer Menu, and press 2-5-4 + MENU on the Installer
Remote. Add/edit custom text labels to channel on-screen displays.
Note that digital channels often have a broadcaster generated label
(see 2-5-4 + MENU procedural information on page 49). When you
are finished, press MENU to exit 2-5-4 + MENU Mode.
Run Auto Tuning, edit channels, and select
familiar channel trademarks/logos using
Channel Menu options.
* This step prevents end users from
accessing channel settings (i.e., the
Channel Menu will be inaccessible/
grayed out).
CHANNEL Enter Move
Auto Tuning
Manual Tuning
Channel Edit
Channel Label
6. Verify the STB1000 setup.
At this point, verify that the channel lineup, channel icons, and custom labels are
correct. Make sure the display features are set per your requirements.
7. Lock the channel lineup.
Enter the Installer Menu. Then, set item 028 CH. OVERIDE to 000 and press
ENTER to lock the channel lineup and restrict access to the STB1000 setup
menus. Press ENTER again to save your changes and exit the Installer Menu.*
The Master STB1000 Setup is now ready to be copied to a USB memory device or
a clone programmer (see cloning information in this document).
028 CH. OVERIDE 000
