40 206-4147
Commercial Mode Setup for Master STB1000
Typical STB1000 Installer Menu
Adjust the settings for these
Installer Menu items.
1. Set Installer Menu items.
This step provides specifi c instruction only on the Installer Menu
items that should be set on a Master TV. Refer to pages 43 to 48
for detailed information on all Installer Menu items.
a) Make sure the STB1000/display panel is ON. Then, use the
Installer Remote to enter the STB1000 Installer Menu: Press
MENU repeatedly until the on-screen setup menus lock up, and
then press 9-8-7-6 + ENTER.
b) Set Installer Menu item 117 FACT DEFAULT to 001 and press
ENTER on the Installer Remote.
This exits the Installer Menu and then clears all Installer Menu
custom settings, channel labels/icons, etc. and reloads the
factory default settings. The value will change back to 0 after
the internal STB controller (Protocol Translator Card [PTC]) has
been restored to factory default condition. This step ensures
that the STB Channel Memory will be the active channel lineup.
c) Re-enter the Installer Menu as described above, and set
Installer Menu item 003 BAND/AFC, as appropriate.
• Broadcast: Set to 000.
• CATV: Set to 001 (default).
• HRC: Set to 002.
• IRC: Set to 003.
d) Set any other Installer Menu items that affect your TV program-
ming network to the required confi guration. For example, enable/
disable Aux sources, set a Start Channel, etc.
e) After you have adjusted all required Installer Menu item
settings, press ENTER once on the Installer Remote to save
your changes; then, press ENTER again to exit the menu.
2. Set up display features.
On-screen setup menus control the features of the display (see
pages 15 to 38). Press MENU on the Installer Remote to access
the setup menus, and then set Channel, Picture, Audio, Lock,
Time, etc. options to the desired configurations. See also the
Clonable Menu Features list on page 50.
Note: If desired, you can run Auto Tuning (see step 3) prior to
completing this step.
This section describes how to set up a Master STB1000 when the EBL is in Pass-through Mode.
Note: Disconnect all Aux inputs. Under certain conditions, Auto Tuning (Channel Search) is disabled if
there is an Aux input active.
Note: Refer to “FTG Mode of Operation” on pages 58 to 61 for information on confi guring/editing FTG
Channel Map and Installer Menu settings for an individual STB1000 in FTG Mode.
(Continued on next page)
Set the display features to the desired
configuration for the end user.
CHANNEL PICTURE AUDIO TIME
INPUT USB OPTION LOCK
LODGING PTC INSTALLER MENU
000 INSTALLER SEQ 000
UPN 000-000-000-000 ASIC 20E7
PTC V1.00.00 STB V3.00.00
117 FACT DEFAULT 001
003 BAND/AFC 00X
