6 Features & Specifications
© Travis Industries 100-01166 4040907
Installation Options
•
Freestanding
•
Freestanding in an Alcove
•
Freestanding in a Mobile Home
•
Masonry Fireplace Insert
•
Zero-Clearance (Metal) Fireplace Insert
Features
•
EPA Phase II Approved
•
1.6 Cubic Foot Firebox Volume
•
Single Operating Control
•
Accepts Logs Up to 18" Long
•
Steel Plate Construction (1/4" & 3/16")
•
Heavy Duty Refractory Firebrick
•
Optional High-Tech Blower
Heating Specifications
Approximate Maximum Heating Capacity (in square feet)* 750 to 1,400 (stove)
750 to 1,200 (insert)
Maximum BTU's per Hour (Cord Wood Calculation) 66,800
Overall Efficiency (Oregon Method) 70.0 %
Maximum Burn Time Up to 8 Hours
* Heating capacity will vary depending on the home's floor plan, degree of insulation, and the outside
temperature. It is also affected by the quality and moisture level of the fuel.
Dimensions
Insert Dimensions:
Depth into Fireplace** ........13-1/2"
Onto Hearth*** ....................3"
* For inserts, add 3/4" for the flue collar.
** ZC (metal) fireplaces requre 14-1/2".
*** Does not include hearth protection.
Note:
Measure side, corner,
and back clearances
from the stove top.
5-7/8"
20"*
23-5/8"
16-1/4"
Height:
Steel Legs (discontinued)..26-1/2"
Sculptured or Cast Legs....27-7/8"
Pedestal.............................31-7/8"
The flue collar protrudes
3/4" above the stove top
18-5/8"
Figure 1
Emissions
4.4 Grams Per Hour (EPA Phase II Approved) – Tests conducted by E.E.S.P.C.
