01: Compressor
14
01: Compressor
This effect compresses the input signal to regulate the level and give a “punchy” effect. It is useful for gui-
tar, piano, and drum sounds.
a Sensitivity 1…100 Sets sensitivity. ☞ P.14
b Attack 1…100 Sets attack amount. ☞ P.14
c EQ Trim 0…100 Equalizer input level
d Pre LEQ Gain [dB] –15.0…+15.0dB Low EQ gain
e Pre HEQ Gain [dB] –15.0…+15.0dB High EQ gain
f Ouput Level 0…100 Compressor output level. ☞ P.14
g
Wet/Dry Dry, 1:99…99:1, Wet Sets the balance between the effect and dry sounds.
Src None…Tempo Modulation source of effect balance
Amt –100…+100 Modulation amount of effect balance
a: Sensitivity
f: Output Level The “Sensitivity” parameter sets the sensitivity of the compressor. If this param-
eter is set to a higher value, lower level sounds will be boosted. With a higher
Sensitivity, the overall volume level is higher. To adjust the final volume level,
use the “Output Level” parameter.
b: Attack This parameter controls the attack level.
In
Wet / Dry
Mono In - Mono Out
EQ Trim LEQ HEQ
Compressor
Output Level
Envelope - Control
Sensitivity=100
Sensitivity=40
Dry
Wet
Time
Level
Compressor - Sensitivity
Louder
Dry
Wet
Time
Level
Attack=80
Attack=20
Compressor - Attack
