English-2-6

3) CAMERA MOUNT BRACKET(SBR-110) & STANDARD CAMERA(SOC-C120)

(1) Overview

CAMERA MOUNT BRACKET (SBR-110S) is used to attach the camera to a wall, ceiling or shelf.

(2) Specifications

Use : Indoor

Installation : Wall or Ceiling

Dimensions : 2.25 (W) X 1.86(H) X 3.95(L) inches

Weight : 0.29 Ibs

Operating Temperature : 32°F ~ 104°F

(3) Accessories

SCREW (M4 X L15) : 3 pcs

(4) Installation

Explains the installation of CAMERA MOUNT BRACKET installation, as well as installation of the

camera onto the CAMERA MOUNT BRACKET.

•

Choose an installation site that can sufficiently support the weight of the equipment to be

installed.

•

Attach the camera mount bracket to the wall using the supplied screws (M4 X L15).
