RM-V210 3-276-523-11 (1) US/ES
RM-V210 3-276-523-11 (1) US/ES
RM-V210 3-276-523-11 (1) US/ES
RM-V210 3-276-523-11 (1) US/ES
RM-V210 3-276-523-11 (1) US/ES
Installing the Batteries
Before replacing the batteries, have new ones ready beforehand.
Slide open the battery compartment and insert two size AA (R6)
batteries (not supplied).
Be sure to line up the + and – on the batteries with the + and – on the
battery compartment.
1
2
When to replace the batteries
Under normal conditions, batteries will last up to one year. If the
Commander does not operate properly, the batteries might be worn
out. Replace the batteries with new ones.
Notes
• Replace both batteries with new ones.
• Do not take more than 3 minutes to replace the batteries; otherwise,
your setting of the code numbers will be erased.
Notes on Batteries
• Do not mix old batteries with new ones or mix different types of
batteries together.
• If the electrolyte inside the battery should leak, wipe the
contaminated area of the battery compartment with a cloth and
replace the old batteries with new ones. To prevent the electrolyte
from leaking, remove the batteries when you plan not to use the
Commander for a long period of time.
For the customers in the U.S.A.
WARNING
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
You are cautioned that any changes or modifications not expressly
approved in this manual could void your authority to operate this
equipment.
Setting Up the Remote Commander
About Presetting the Commander
The Commander is preset at the factory to operate Sony brand
components.
If you’re using the Commander with a Sony component, you won’t
need to preset the Commander before you start using it.
To set up the Commander to use with other (non-Sony)
manufacturers’ components, or to use with a component that is not
preset at the factory, you’ll need to follow the instructions in this
manual to preset the Commander with the correct code number for
your components. (See the supplied “Component Code Numbers”
also).
Notes
• The Commander can be set up to operate only one component per
button – unless their code numbers happen to be the same. For
example, you cannot set up the Commander to operate a Sony TV
and a Panasonic TV simultaneously (because they use different
code numbers).
• You may not be able to operate even a Sony brand component with
the factory presetting. In such a case, follow the procedure in
“Setting the Code.”
Setting the Code
Follow the steps 1 and 2 below for each component you plan to use
with the Commander.
Step 1: Entering the Code Number
1 See the supplied “Component code
numbers”, and find the four-digit code
number for the desired component.
If more than one code number is listed, use
the number that’s listed first.
For example, if you’re setting up a Sony
TV, you would use the code number 8201.
If your component isn’t listed, see
“Searching for the Correct Code.”
2 Press SET more than two
seconds.
The SET indicator lights up.
3 Press the button of the
component that you want to
set up.
The SET indicator lights up.
4 Press the Number buttons to enter the four-digit
component code number.
5 Press ENTER. The SET indicator turns off. If the SET
indicator flashes five times before lighting up, it
means that the setup is incomplete. Confirm the
component code number and start over from Step 4.
If the code setting is not finished properly
If you do not input anything into the Commander within 20 seconds
between each step, or if you press SET while setting the component
code, the setup procedure will be canceled.
Start over from Step 2.
Step 2: Checking if the Code Number Works
1 Power on the component you want to set up.
2 Aim the Remote Commander at the component and press a button
to check if that button works.
For example, press the POWER button to see if it works on your
component .
3 Check that the other buttons of the Commander is operating the
corresponding functions of the component.
You can write down the code number on the label inside the
battery compartment lid.
If the Commander Doesn’t Seem to Be Working...
• First, try repeating these setup procedures using the other codes
listed for your component (see the supplied “Component Code
Numbers”).
• If – after trying all the codes listed for your component – you still
cannot get the Commander to work properly, try the search
method described in “Searching for the Correct Code.”
Searching for the Correct Code
You can find a code number available for a
component that doesn’t have one in the
supplied “Component code numbers.”
Before starting the Search function
Set each component to the following status so
that the Search function works effectively.
TV, DVD Home Theater: Power-on
Other components: Power-off
* If any of these components are assigned to any
of the Component Select buttons, you can set a
component code using the Search function.
1 Press SET more than two seconds. The SET indicator lights up.
2 Press the Component Select button for the desired component.
The SET indicator lights up.
3 Press CH + or CH – and POWER in turn until the component
reacts as follows:
TV, DVD Home Theater: Powers off
Other components: Powers on
Press CH + to go to the next code number.
Press CH – to go back to the previous code number.
The SET indicator flashes once after the numbers have turned one
cycle.
One cycle means, for example, that the commander finishes
searching all the component code numbers allocated to the
component.
4 Press ENTER.
The SET indicator and the Component button turn off.
If the SET indicator flashes five times before turning off, it means
that the setup is incomplete. Start over from Step 3.
If the component does not operate properly, repeat steps 1 to 4 and
search for another code.
If you still cannot get the Commander to work properly, see
“Troubleshooting.”
Operating a Component
1 Press the button of the desired component on the Commander.
TV
VCR
CBL
DVD
2 Point the Commander directly at the component.
3 Press the button for the function you want to use.
See “Remote Button Descriptions” for complete descriptions of the
buttons on the Commander.
Notes on Using the Remote Commander
Basically, use this Commander in the same way as the Commanders
supplied with your components.
• Using this Commander will not increase the functions of your
components. The functions of the Commander are limited to the
functions of the components themselves. For example, if your TV
does not have a MUTING function, MUTING on this Commander
will not function with your TV.
• Some functions of the component may not work with this
Commander.
• If your cable box can control volume, be sure to set its volume
switch to a medium position. If the volume on the cable box is
turned down completely, you will not be able to adjust your TV’s
volume with the Commander.
English
3-276-523-11(1)
Remote Commander
RM-V210
Operating Instructions
Manual de instrucciones (parte posterior)
© 2007
Sony Corporation
Printed in China
Operating a DVD
2 To change the input mode.
3 and qd
Number buttons : To set items
selected from the screen.
4 To select numbers 10 and
above.
8 To show the current play status
on the screen.
9 To bring up the Master Guide.
q; To return to the previous
screen.
qd To enter the setting. To set
items selected from the screen.
qf To switch the subtitle.
qg
CH+: Channel up.
CH–: Channel down.
qh To select a deck.
qj To switch the subtitle.
qk To display the DVD menu.
Specifications
Operable distance
Approx. 7 m (23 ft) (varies depending of the
component of each manufacturer)
Power requirements
Two size AA (R6) batteries (not supplied)
Battery life
Approx. 1 year (varies depending on frequency of
button use - up to approx. 300 times per day.)
Dimensions
Approx. 53
Ч
220
Ч
29 mm (w/h/d)
(2
1
/
8
Ч
8
3
/
4
Ч
1
3
/
16
in.)
Mass
Approx. 108 g (3.8 oz.) (not including batteries)
Design and specifications are subject to change without notice.
The validity of the CE marking is restricted to only those countries
where it is legally enforced, mainly in the countries EEA (European
Economic Area).
Troubleshooting
If you have problems setting up or using the Commander:
• When setting up the Commander, carefully go through the procedures
described in “Setting the Code.” If the code that’s listed first for your
component doesn’t work, try all the codes for your component - in the order
in which they’re listed. If all the codes fail to work (or if your component is
not listed in this manual), try using the procedures in “Searching for the
Correct Code.”
• Check that you’re aiming the Commander directly at the component, and that
there are no obstructions between the Commander and the component.
• Make sure the batteries you’re using are not worn out, and that they’re
inserted correctly.
• Check that the button of the TV, VCR, CBL, or DVD is pressed to choose your
desired component.
• Check that the component has infrared remote capability. For example, if
your component didn’t come with a remote commander, it probably isn’t
capable of being controlled by a remote commander.
• Should any problem persist, reset the Commander to the factory setting by
pressing the POWER, INPUT and VOL– buttons simultaneously.
For the customers in the U.S.A.
Customer Support Information
If – after you’ve read through this manual – you still cannot get the
Remote Commander to work properly, call the Sony Customer
Support Helpline at 1-800-822-2217.
Operating a TV
2 To change the input mode.
3, 4 and qd
To change the channel. For
example, to change to channel
5, press 0 and 5 (or press 5 and
ENTER).
8 To display the current channel
on TV.
9 To bring up Master Guide.
q; To exit the menu.
qf To operate the Picture-in-
Picture function.
qg
CH+: Channel up.
CH–: Channel down.
qh To operate JUMP, FLASHBACK
or CHANNEL RETURN function
on the TV.
qj To operate SLEEP function on
the TV.
qk To call up the MENU display.
ql To move the cursor upward,
downward, to the left, to the
right, or to enter the selection.
w; To call up the option menu.
wa To select TV input source.
ws A: VIDEO 1
B: VIDEO 2
C: VIDEO 3
D: VIDEO 4
.
: VIDEO 5
:
VIDEO 6
:
VIDEO 7
>
:
VIDEO 8
m
: HDMI select
N
:
HDMI 1
M
:
HDMI 2
z
REC: Component video
connection select
x
:
Component video
connection 1
X
:
Component video
connection 2
wg To use the “FAVORITE”
function.
ql To move the cursor upward,
downward, to the left, to the
right, or to enter the selection.
w; To call up the “TOOLS” menu.
wa N:
To play.
m
:
To rewind.
M
:
To fast-forward.
z
REC: To record, press N
while pressing zREC.
x
:
To stop.
X
:
To pause.
.
: To proceed to the
previous location.
>
:
To proceed to the next
location.
:
To operate “ Flash –.”
:
To operate “ Flash +.”
ws B: open/ close
D: To display the Top Menu.
A: To call up the setup menu.
wd PAGE+: To select DVD deck.
PAGE-: To select HDD deck.
wf To display the title menu.
Operating a digital satellite receiver
2 To switch the output of the
digital satellite receiver to the
TV. (When you connect a TV
cable or antenna to the receiver,
the output switches between a
TV and SAT program.)
3, 4 and qd
To change the channel. For
example, to change to channel
5, press 0 and 5 (or press 5 and
ENTER).
8 To turn on the display.
9 To bring up the Master Guide.
q; To exit the mode.
qf To call up the DISH menu.
qg Channel up: +
Channel down: –
qh To tune to the last tuned
station.
qj To call up the PVR menu.
qk To call up the MENU display.
ql To move the cursor upward,
downward, to the left, to the
right, or to enter the selection.
w; To bring up the Station Index.
wa N:
To play.
m
:
To rewind.
M
:
To fast-forward.
z
REC: To record, press N
while pressing zREC.
x
:
To stop.
X
:
To pause.
.
: To proceed to the
previous location.
>
:
To proceed to the next
location.
:
Replay
:
Advance
ws A: RED button
B: GREEN button
C: YELLOW button
D: BLUE button
wd PAGE+: Page up.
PAGE-: Page down.
wf To call up the title of the
recorded program.
wg To use the “FAVORITE”
function.
SET
TV
VCR
CBL
DVD
POWER
A
B
C
D
1
2
3
4
5
6
7
8
9
VOL
CH
0
PIP
INPUT
SLEEP
INFO
PAGE
GUIDE
MENU
LIST
FAV
EXIT
TOOLS
RECALL
MUTING
ENTER
OK
Operating a VCR
2 To change the input mode.
8 To expose the on-screen
display.
qf To switch the antenna output.
qg
CH+: Channel up
CH–: Channel down
qh To select a deck.
wa N:
To play.
x
:
To stop.
m
:
To rewind.
M
:
To fast-forward.
z
REC: To record, press N
while pressing zREC.
X
:
To pause.
Operating a DVR (Digital video recorder)
2 To change the input mode.
3 and qd
To change the channel.
For example, to change to
channel 5, press 0 and 5 (or,
press 5 and ENTER).
8 To turn on the display.
9 To bring up Master Guide.
q; To clear the setting.
To exit the setting menu.
qg
CH+: Channel up .
(*PAGE+) Page up.
CH–: Channel down.
(*PAGE–) Page down.
qh To operate JUMP or
CHANNEL RETURN
qj To call up “Tivo” menu.
qk To call up the MENU display.
ql To move the cursor upward,
downward, to the left, to the
right or to enter the selection.
wa N:
To play.
m
:
To rewind.
M
:
To fast-forward.
z
REC: To record, press N
while pressing zREC.
x
:
To stop.
X
:
To pause.
.
: To proceed to the
previous location.
>
:
To proceed to the next
location.
:
To operate “ Flash –.”
:
To operate “ Flash +.”
ws D: (*Live TV)
To bring up Master Guide.
A: (*REPLAY)
To replay.
Or to go into REC/REVIEW
mode during play. (After about
5-second rewind, replay
begins.)
wd PAGE+ : (*THUMBS+)
To select the desired recorded
program.
(It is necessary to have
recorded the desired program.)
PAGE– : (*THUMBS–)
To select the desired recorded
program.
(It is necessary to have
recorded the desired program.)
wf (*LIST)
To call up the title of the
recorded program.
* This key corresponds to Tivo service or the replay service. Refer to its
instruction manual for details.
Operating a cable box
2 To change the input mode.
3, 4 and qd
To change the channel
(for example, to change to
channel 5, press 0 and 5, or
press 5 and ENTER).
8 To turn on the display.
9 To switch the EPG display to
on/off.
q; To exit the setting menu.
qg
CH+: Channel up.
CH–: Channel down.
qh To toggle the current /previous
channel.
qk To call up the MENU display.
ql To move the cursor upward,
downward, to the left, to the
right, or to enter the selection.
wa N:
To play.
m
:
To rewind.
M
:
To fast-forward.
z
REC: To record, press N
while pressing zREC.
x
:
To stop.
X
:
To pause.
.
: To proceed to the
previous location.
>
:
To proceed to the next
location.
ws A: To operate “A” button.
B: To operate “B” button.
C: To operate “C” button.
wd PAGE+: Page up.
PAGE-: Page down.
wf To call up the title of the
recorded program.
wg To use the “FAVORITE”
function.
Component code numbers /
Números de código de componentes
English
DVR (digital video recorder), SAT (digital satellite receiver),
Cable box, TV, DVD Home Theater, DVD and VCR
The following tables show brand names and their corresponding code numbers.
Español
DVR (Videograbadora digital), SAT (Sintonizador de recepción vía satélite
digital), adaptador para cablevisión, Televisor, Sistema de cine doméstico en
DVD, DVD (reproductor de discos DVD) y Videograbadora
Las tablas que se presentan a continuación muestran las marcas y los números de código
correspondientes.
To set a Component Code (see the instruction manual for details)
Para introducir un código de componente (consulte los detalles en el manual
de instrucciones)
Continued on reverse side / Continúa en el reverso
Operating a DVD Home Theater
2 To change the input mode.
3 and qd
Number buttons: To set items
selected on the screen.
4 To select numbers 10 and
above.
6
VOL+: AMP volume up
VOL–: AMP volume down
7 AMP volume muting
8 To show the current play status
on the screen.
9 To change the sound.
q; To return to the previous
screen.
qf To switch the subtitle.
qg
CH+: Tuner +
CH–: Tuner –
qk To call up the MENU.
ql To move the cursor upward,
downward, to the left, to the
right, or to enter the selection.
w; AMP menu
wa N:
To play.
m
:
To rewind.
M
:
To fast-forward.
z
REC: To record, press N
while pressing zREC.
x
:
To stop.
X
:
To pause.
.
: To proceed to the
previous location.
>
:
To proceed to the next
location.
:
To operate “ Flash –.”
:
To operate “ Flash +.”
ws B: open/ close
A: To call up the setup menu.
C: Disc skip
D: To display the Top Menu.
wg To call up MEMORY.
ENTER
Remote Button Descriptions
General
1 To set up the Commander,
press SET more than two
seconds.
6 Volume up: +
Volume down: –
7 To mute the volume on a TV
or a DVD Home Theater.
qa To turn on and off the power
of the selected component.
qs Component select buttons.
Press to select a component to
operate.
About tactile dots
The number 5 button, the N button and CH+ each have a tactile dot for
convenient use.
Note on the VOL+/- and MUTING buttons
The Commander controls or mutes the TV’s volume when you select a visual
component. The Commander outputs the signals to control or to mute a TV or
DVD Home Theater’s own volume when you have set one of these
components.
Notes
• There may be cases you may turn on/off the cable box by pressing CH+ or
CH– on the Commander.
• If your cable box can control volume, be sure to set its volume control to a
medium position. If the volume on the cable box is turned down completely,
you will not be able to adjust your TV’s volume with the Commander.
SET indicator
SET
TV
VCR
CBL
DVD
POWER
1
2
3
4
5
6
7
8
9
VOL
CH
0
PIP
INPUT
SLEEP
INFO
RECALL
MUTING
ENTER
1
3
2
4
3
SET
SET
TV
VCR
CBL
DVD
POWER
1
2
3
4
5
6
7
8
9
VOL
CH
0
PIP
INPUT
SLEEP
INFO
RECALL
MUTING
ENTER
2
3
4
5
SET
TV
VCR
CBL
DVD
SET
Code No.
SET
c
c
ENTER
TV
VCR
CBL
DVD
c
Brand
Sony
Bose
Insignia
JVC
LG
Nexxtech
Onkyo
Panasonic
Sharp
Yamaha
Zenith
DVD Home Theater (DVD/Receiver combo)/
Sistema de cine doméstico en DVD
(combo de receptor de DVD)
Code No.
4501, 4502, 4503, 4504, 4505
4512
4515
4507
4514, 4516
4515
4509
4506
4510
4511
4513
SAT(Digital satellite receiver)/
SAT(Sintonizador de recepción vía satélite digital)
DirecTV
Dish Network
Digital TV Tuner
Brand
Code No.
Code No.
Code No.
Sony
3001,3011,3012
—
—
DirecTV
3013, 3017, 3018,
—
—
3019, 3023, 3024
Dish Network
—
3010, 3014, 3025
—
General Electric
3019
—
—
Hitachi
3005
—
—
Hughes
3004
—
—
Humax
3402
—
—
JVC
—
3010, 3014
—
Magnavox
3018
—
—
Panasonic
3003
—
—
Philips
3018
—
—
Proscan
3002, 3007, 3019
—
—
RCA
3002, 3007, 3019,
—
—
3021
Samsung
3017, 3022
—
3404
Sylvania
—
—
3403
Toshiba
3006
—
—
Usdigital
—
—
3401
Cable box/Adaptadores para cablevisión
Brand
Code No.
Sony
3101
ABC
9405
Adelphia
3107, 3110
Advanced Newhouse
3107
Altrio
3107
Americast
3105
Atlantic Broadband
3107
Bell South
3105
Blue Ridge
3107
Brigth House
3107
Cablevision
3107
Charter
3107
Comcast
3107
Cox
3107
General Instrument
3103, 9002, 9003, 9004, 9005, 9006, 9007, 9008, 9018,
9022, 9043, 9044
Gnc
3105
Hamlin
9022, 9023, 9024, 9025, 9026
Illico
3107
Jerrold
3103, 9002, 9003, 9004, 9005, 9006, 9007, 9008, 9018,
9022, 9043, 9044
Memorex
3106
Motorola
3103, 3110, 3111
NET
9042
Oak
9027, 9028, 9029
Pace
3107
Panasonic
9019, 9020, 9021
Paragon
3106
Philips
3104
Pioneer
3107, 9014, 9015
Pulsar
3106
Regal
9022, 9023, 9024, 9025, 9026
Rodgers
3107
Runco
3106
Scientific Atlanta
3102, 3107, 3108, 3109, 9009, 9010, 9045, 9046
Seren
3107
Sigecom
3107
Susquehanna
3107
Time Warner
3107
Tocom
9016, 9017, 9043
Toshiba
3106
Videotron
3107
Wideopenwest
3105, 3107
Zenith
3105, 3106, 9013
DVD
Brand
Code No.
Sony
0201, 0202, 0203, 0024, 0030, 0211
Advent
0048
Aiwa
0015
Apex
0047
Broksonic
0214
Cyber Home
0034, 0035, 0226
Daewoo
0029
Denon
0002, 0017, 0205
Emerson
0040, 0228
Funai
0220
GO VIDEO
0042, 0212, 0233
Gpx
0046, 0049
Humax
0232
ILO
0227, 0230
Insignia
0042, 0215
JVC
0007, 0208
Kenwood
0050, 0051
LG
0218
Magnavox
0225
Marantz
0012
Panasonic
0205, 0213, 0002
Philips
0012, 0221, 0231
Pioneer
0004, 0019, 0021, 0204
Samsung
0014, 0212, 0229
Sansui
0214
Sharp
0219
Sylvania
0215, 0220
Symphonic
0040, 0041
Terapin
0036
Toshiba
0209
Yamaha
0205
Zenith
0218
Tivo
ReplayTV
DVR (Digital Video Recorder)/
DVR (Videograbadora digital)
Brand
Code No.
Code No.
Sony
3201, 3205, 3206
—
Humax
3202, 0413
—
Panasonic
—
3203
Philips
3202, 0412
—
Pioneer
0413
—
ReplayTV
—
3203, 3204
Tivo
3201, 3202
—
Toshiba
0413
—
Component that can be preset
TV
VCR/Cable box/Digital satellite
receiver/DVD/TV/Digital video
recorder/DVD Home Theater
Button
TV
VCR
CBL
DVD
Factory setting
Sony TV
Sony VHS VCR
Sony Cable box
Sony DVD player
