Infinity Powered Subwoofer Basslink II None User Manual
Page 2

- CONTENTS -
SPECIFICATIONS ………………………………….……..1
PACKAGING…..………………………………….………..2
CONNECTIONS/APPLICATIONS………………………..3
CONTROLS AND FUNCTIONS.……...……..…...…...…6
BASIC TROUBLESHOOTING..…….…….………………8
DISASSEMBLY PROCEDURE.……...….…..…...…...…9
EXPLODED VIEW…………………………………..……10
AMPLIFIER BLOCK DIAGRAM…………………………11
ELECTRICAL PARTS LIST ……………………………. 12
P.C.B. DRAWINGS….…………………………………….18
IC/TRANSISTOR PINOUTS…………………………….. 30
SCHEMATICS.................................................................31
Basslink II Specifications
Output Power (14.4V supply)
250W RMS 1% THD
Type of Amplifier
AB
Frequency response:
20Hz – 120Hz
Maximum input signal:
4.0V
Maximum sensitivity:
50mV to 4V Line-level input
1V to 16V High-level input
Input
Impedance
20K
Ω
Idle
Current
<800mA
Signal to Noise
>100dB (A-weighted ref to full power)
Crossover Type
Fixed LP @ 12dB per octave
Crossover Range
Variable 50 – 120 Hz
Bass
EQ
40Hz
(-6dB
to
+3dB)
Phase
Control
0
and
180°
Min Current Draw (Idle)
<800mA
Remote Current Draw
<3.5mA
Max Current Draw
26A
DC
Offset
<30mV
Bass Boost
-6dB to +3dB @ 40Hz
Auto Turn-On
2 -10min (Time to turn Off)
Operating Voltage
10 – 16 VDC
Overall Dimensions (L x W x H):
15-1/16" x 8-3/4" x 15-5/16"
(383mm x 223mm x 389mm)
Sub Level Control (w/ housing):
2-3/16" x 2-5/16" x 7/8"
(56mm
x
59mm
x
23mm)
Sub Level Control (w/o housing):
2-3/16" x 1-5/16" x 3/4"
(56mm
x
34mm
x
20mm)
Fuse:
25A
Infinity continually strives to update and improve existing products, as well as create new ones. The specifications and details in
this and related JBL publications are therefore subject to change without notice.
1
Powered Subwoofer
Basslink II
