1100 Keyboard bezel
For access, remove following FRUs, in order:
v “1010 Battery pack” on page 76
v “1020 Hard disk drive” on page 77
v “1030 DIMM cover” on page 79
v “1040 DIMM” on page 80
v “1050 Backup battery” on page 81
v “1060 Keyboard” on page 82
1
2
2
2
2
3
Step Screw (quantity) Torque
1 M2 × 13.5 mm, nylon-coated (1) 0.245 Nm
(2.5 kgfcm)
2 M2 × 6 mm, nylon-coated (4) 0.245 Nm
(2.5 kgfcm)
3 M2 × 4 mm, nylon-coated (1) 0.245 Nm
(2.5 kgfcm)
(continued)
Removing and replacing a FRU
104 MT 2672, 2673, 2884, 2885
