Specifications
Design and specifications are subject to change without
notice.
General
Power requirement 14.4 V DC
(11-16 V allowable)
Load impedance 4 ohms
Max. power output 40 W x 4
Tone controls +/–8 dBm
Bass 100 Hz
Treble 10 KHz
Dimensions
Depth
7.6 inches (192 mm)
Width 7 inches (178 mm)
Height 1.97 inches (50 mm)
Mounting dimensions
Depth 6.65 inches (169 mm)
Width 7.17 inches (182 mm)
Height 2.09 inches (53 mm)
Weight 3.88 lbs. (1.75 kg)
FM selection
Tuning range
(optional) 87.5-108 MHz (China/Europe)
87.5-108 MHz (USA)
IF range 10.7 MHz
Usable sensitivity 15 dBu V (-30 dB)
Signal-to-noise ratio 50 dB
Stereo separation 30 dB (1 KHz)
Frequency response 30-15000 Hz
