49
6
DSC OPERATION
6
D D NMEA Output
Select an NMEA Output function from OFF, All Station or List
Station.
When receiving position acknowledgment, the transceiver
outputs it to the external equipment via the NMEA connector.
q Push [MENU] to enter the DSC menu.
w Rotate [DIAL] to select “S
Se et t u up p,” push [DIAL•ENTER].
e Rotate [DIAL] to select “N NM ME EA A O Ou ut tp pu ut t,” push
[DIAL•ENTER].
r Rotate [DIAL] to select the NMEA Output function from
OFF, All Station or List Station.
• List Station : Outputs the position data from the specified vessels
listed on the DSC individual ID screen.
• All Station : Outputs the position data from all vessels.
• OFF
: Does not output any position data to external equip-
ment.
t Push [DIAL•ENTER] to set the condition.
• Push [CLR] to cancel and return to the set up menu.
--DSC Menu--
NMEA Output
˘
List Station
All Station
OFF
Exit / ENT ENT˘OK> OK>
--DSC Menu--
Select Item
DEL:INDV ID
DEL:Group ID
Offset Time
MMSI Check
Auto ACK
˘ NMEA Output
--DSC Menu--
Select Item
POS Report Reply
Polling Request
Polling Reply
Received Calls
Distress Setting
˘Set up
