Connecting Device
The DPP-350 is designed to use different methods of
communications. Care must be taken to ensure that the DPP-350
USB or Serial connector and PDA & Smartphone connector are not
accidentally damaged. The figures below show how to attach the
different device to the DPP-350.
♦ Serial / USB ( Cabled ) Version:
• Connect the DPP-350 using Mini USB or Serial cable is shown in
the figure below.
Serial Port
USB Port
Figure 11
♦ BLUETOOTH
®
( Wireless ) Version:
• The DPP-350 Bluetooth ® version uses Bluetooth ® wireless
technology to connect to Bluetooth ® enable devices. See page
18 for details on Bluetooth ® setup.
Figure 12
. . . . . . . . . . . . . . . . . . . .
