EPS1U Power Supply Design Guide, V1.1
6.7 Capacitive Loading
STATUS
Required
The power supply shall be stable and meet all requirements with the following capacitive loading ranges.
Table 13: Capacitive Loading Conditions
Output
MIN
MAX
Units
+3.3 V
10
6,800
µ
F
+5 V
10
4,700
µ
F
+12 V
10
11,000
µ
F
-12 V
1
350
µ
F
+5 VSB
1
350
µ
F
6.8 Ripple / Noise
STATUS
Required
The maximum allowed ripple/noise output of the power supply is defined in Table 14 below. This is measured
over a bandwidth of 0 Hz to 20 MHz at the power supply output connectors. A 10
µ
F tantalum capacitor in
parallel with a 0.1
µ
F ceramic capacitor are placed at the point of measurement.
Table 14: Ripple and Noise
+3.3 V
+5 V
+12 V
-12 V
+5 VSB
50 mVp-p
50 mVp-p
120 mVp-p
120 mVp-p
50 mVp-p
