19
Internal Trackpad Interface
There is a 8-pin connector used to interface with the internal trackpad. It will be
disabled when external mouse has been installed. The trackpad is hardware-
connected to PS/2 port, hardware-compatible to Microsoft PS/2 mouse and software-
compatible to Microsoft mouse mode. The following is the pin configuration for the
connector:
Pin Description
1 VCC
2 PS/2 DATA
3 PS/2 CLK
4 SW Right
5 SW Left
6 GND
7 N.C
8 N.C
External Monitor Interface
Pin Description
1 BRED
2 BGREEN
3 BBLUE
4 N.C
5 GND
6 GND
7 GND
8 GND
9 N.C
10 GND
11 N.C
12 DDCDATA
13 BHSYNC
14 BVSYNC
15 DDCCLK
RGB Out
Output Impedance: 75
Ω
RGB peak voltage: 0.7Vpp
