Zone 2 —Continued
Here you can turn on Zone 2, select an input source, and
adjust the volume.
Note:
To control Zone 2 with the remote controller, you must
press the [ZONE 2] button first.
Notes:
• If the Sleep function has been set, the Zone 2 compo-
nent will turn off along with the AV receiver when the
specified sleep time expires. To use the Sleep function
with Zone 2 only, set the Sleep function and then set
the AV receiver to Standby.
• Only analog input sources are output by the ZONE 2
LINE OUT and ZONE 2 SPEAKERS terminals. Dig-
ital input sources are not output. If no sound is heard
when an input source is selected, check if it’s con-
nected to an analog input.
• Since the Zone 2 function and the REC OUT outputs
use the same circuitry, if the [Rec Out] function is
used, Zone 2 will be turned off.
• While Zone 2 is being used, listening modes that need
surround back speakers (i.e., Dolby Digital EX, DTS-
ES, and THX Surround EX) are unavailable.
• While Zone 2 is on, functions will not work.
• You can’t select different radio stations for Zone 2 and
the main room. For example, if you an FM station for
the main room, that station will also be used in Zone 2.
Using Zone 2
1 Point the remote controller at the
AV receiver and press the
[ZONE 2] button followed by the
[On] button.
This turns on Zone 2 and the AV
receiver’s 12V TRIGGER OUT.
2 To select the Zone 2 input source
with the remote controller, press
the [ZONE 2] button followed by
an input selector button.
If you select AM or FM, you can use
the remote controller’s [TUNER] but-
ton to select the band.
To perform steps 1 and 2 on the
AV receiver, press the [ZONE 2]
button, and then use the Control-
ler [
]/[ ] buttons within five
seconds.
The name of the selected Zone 2 source
appears on the display.
Pure A
On Standby
T V
Last Memory Angle Subtitle Audio
Memory Search A-B Repeat
RC- 585M
T V CH
TV VOL
--/---
Tape
Input I
Test Tone CH SEL
Surround THX
Direct
Stereo All ST
Level+ Level-
L Night
DSP DSP
SAT T V VCR Cable
DVD Receiver C D
+10 0 Clear
1 2 3
4 5 6
7 8 9
+
-
Video Off Open/Close
Macro
1 2 3
MD/CDR
Re-EQ
Input Selector
V 1 V 2 V 3
C D
Phono
Tape
V 4 DVD Multi CH
Tuner
Remote Mode
Zone 2
3
1–4
4
2
1
Zone 2
On
Zone 2
V 1 V 2 V 3
C D
Phono
Tape
V 4 DVD Multi CH
Tuner
To set Zone 2 to the same source as the
main room, press the [ZONE 2] button,
and then use the Controller [
]/[ ]
buttons to select “Zone 2 Sel: Source.”
3 To adjust the Zone 2 volume with
the remote controller, press the
[ZONE 2] button, and then use
the [Level–] and [Level+] buttons.
To do this on the AV receiver,
press the Zone 2 [Level] button,
and then use the Controller [
]/
[ ] buttons.
If the Zone 2 receiver/integrated amp is
connected to the AV receiver’s ZONE 2
LINE OUT L/R jacks, use the volume
control on the receiver/integrated amp.
4 To turn off Zone 2 with the
remote controller, press the
[ZONE 2] button followed by the
[Standby] button.
To do this from the AV receiver,
press the [ZONE 2] button, and
then use the Controller [
]/[ ]
buttons to select OFF.
Zone 2
Level+ Level-
Zone 2
Standby
