ICE0320/0520 Series Service Parts Evaporator
Item
No. ICE0320 ICE0325 ICE0520 ICE0525 Description
1 2051222-01 2051222-01 2051232-01 2051232-01 Evaporator-Full Cube
1 2051222-02 2051222-02 2051232-02 2051232-02 Evaporator-Half Cube
3 2101387-01 2101387-01 2101355-04 2101355-04 Curtain
4 2041338-02 2041338-02 2041338-02 2041338-02 Water Distribution Tube
5 9031122-01 9031122-01 9031122-01 9031122-01 Thumb Screw
6 9031004-19 9031004-19 9031004-19 9031004-19 Washer
7 3012747-01 3012747-01 N/A N/A Curtain Stopper Clip
8 9131413-01 9131413-01 9131413-01 9131413-01 Insulation
9 2021651-01 2021651-01 2021651-01 2021651-01 Divider Panel
10 9051135-05 9051135-05 9051135-05 9051135-05 Evaporator Spillway
11 9051136-08 9051136-08 9051136-06 9051136-06 Evaporator Right Side Mounting Panel
12 9051136-07 9051136-07 9161136-05 9161136-05 Evaporator Left Side Mounting Panel
13 9051135-04 9051135-04 9051135-04 9051135-04 Evaporator Water Return
Model Number
Page 5
