Intermec EASYCODER PL4 User Manual
Page 16
16
EasyCoder PL4 Printer User’s Guide
In addition to the status icons, the LCD control panel can
display many of the printer’s settings and functions as text. Refer
to the next table, “LCD Functions,” for the full set of printer
features that are available with the LCD panel. To set these
functions, see the EasyCoder PL-Series Printer Programmer’s
Reference Manual.
LCD Functions
Function
Default Setting
Options
Sensor Type
Gap
Black mark
Gap
Baud Rate
19200
9600
19200
38400*
57600
115200
Data Bits
8
7
8
WLAN ID**
Factory Set Value
N/A
Label Top-of-
Form
000
Increase (+120 dots max)
Decrease (-120 dots max)
Left Position
000
Increase (+120 dots max)
Decrease (-120 dots max)
LCD Contrast
0
Increase
Decrease
No activity
Timeout**
60 sec.
60 sec.
5 min.
10 min.
30 min.
Custom
Tear-off Position
00
Increase (+120 dots max)
Decrease (-120 dots max)
Media Type
Label
Label
Continuous
LCD Backlight
Off
On
Off
Momentary on with time
delay
Factory Reset
No
No
Yes
