Strip length adjustment assembly, Thermal head assembly, Rear gripper assembly – IDEAL INDUSTRIES 45-935 User Manual
Page 21: Front gripper assembly
21
5
7
12
1
3
9
10
8
2
6
4
11
Item
Qty
Name
Part No.
1
2
Rod Support Bar
K-7554
2
1
Cylinder Bar
K-7555
3
1
Stop Bar
K-7556
4
1
Motor Driver Rod
K-7560
5
1
Follower Rod
K-7561
6
2
Rod
K-7562
7
4
Bearing
21.059
8
2
Fiber Bushing
24.049
9
2
Sprocket
123.049
10
1
Cable Chain
124.005
11
2
Acme Nut
379.026
12
2
Bumper
81.017
Strip Length Adjustment
Assembly
Item
Qty
Name
Part No.
1
1
Assy, Blade Set
K-7763
2
2
Element Support Block
LA2395
3
1
Pin, Short
LA2402
4
1
Pin, Long
LA2403
5
3
Wheel, Head
LA2409
6
4
Screw 4-40 X .38 SCHS
113.098
7
4
Threaded, Standoff
1339.035
8
4
Retaining Ring
482.061
9
1
Assy, Switch
K-7743
10
1
Assy, Stepper Motor
K-7794
11
1
Sprocket
124.003
12
1
Cable Chain
123.005
13
1
Spring, Compression
88.005
14
2
Spring, Extension
89.005
Thermal Head Assembly
Item
Qty
Name
Part No.
1
2
Rear Grip Block
LA2388
2
1
Trigger Block
LA2389
3
3
Cylinder Adapter
LA2411
4
6
Rear Grip Pad
LA2414
5
1
Switch Trigger
LA2422
6
2
Cylinder
391.007
7
3
Cylinder
391.010
8
4
Pin, Gripper
LA2729
9
2
Spring Pin
281.124
Rear Gripper Assembly
Item
Qty
Name
Part No.
1
2
Front Grip Block
LA2381
2
1
Wire Entry Guide
LA2382
3
1
Cylinder Adapter
LA2394
4
2
Spacer, Stop
LA2397
5
1
Sensor Plate
LA2406
6
2
Front Grip Pad
LA2408
7
1
Cylinder
391.008
8
2
Pin, Gripper
LA2729
Front Gripper Assembly
1
3
5
7
9
8
2
6
4
6
7
1
3
9
10
8
2
6
4
11
12
8
5
14
13
6
5
2
3
1
3
5
7
8
2
4
6
4
