Quick Setup Guide
Quick Setup
Guide
I/O Connectors
Note:
DO NOT use RCA S/PDIF and optical S/PDIF at the same time.
S/PDIF-out/in and CD-in Connectors
W
J3
1
5
+5V
Key
SPDIF out
SPDIF in
GND
S/PDIF-out
S/PDIF-in
W
W
1
4
Right audio
channel
Left audio
channel
Ground
Ground
Optical
S/PDIF
CD-in
Rear Panel I/O Ports
PS/2
Mouse
PS/2
K/B
COM
S/PDIF-out
S/PDIF-in
USB 1-2 USB 3-4
LAN
Parallel
Line-out
Line-in
Mic-in
