Quick Setup Guide
1
Quick Setup
Guide
Important:
Before creating RAID, make sure you have installed the Serial/Parallel
ATA drives and connected the data cables otherwise you won’t be
able to enter the NVIDIA RAID BIOS utility.
Serial ATA Connectors
X
1
7
GND
TXP
TXN
GND
RXN
RXP
GND
SATA 1
(J11)
1
7
GND
TXP
TXN
GND
RXN
RXP
GND
SATA 2
(J13)
SATA 3
(J2)
1
7
SATA 4
(J10)
1
7
