7 TP 400-2275-02-BR-S
Engine Group
1 934683 1 CLIP, Speed Wire
2 1960295 4 CAPSCREW, Hex Flange Whizlock, 1/4-20 x 5/8
3 1707334 1 DUCT, Muffler, Top
4 1960624 1 CAPSCREW, Pan Head, Torx, #10-32 x 1/2 (Early Models)
5 1720507 1 BRACKET, Flat (Early Models)
6 1667346 1 CAP, Hex, 3/8-18NPT
7 1673453 1 FITTING, Pipe Elbow Street
8 1720017 1 PIPE, Oil Drain
9 * 1 ENGINE, 18.0HP B&S INTEK
10 960112 2 CLAMP, Hose, 1/2 Diameter Type E
11 1718678 1 HOSE, Fuel
12 1713846 1 KNOB, Soft
13 1714068 1 CONTROL, Throttle 3/16 Cable 35-3/4 Long, No Knob
13 1721446 1 CONTROL, Throttle 3/16 Cable 35-3/4 Long, No Knob (Export)
14 1960536 2 CAPSCREW, Hex Washer Head, 1/4 x 1/2
15 1708764 1 CONTROL, Choke 3/16 Cable 39-1/2 Long w/Knob
16 920427 1 LOCKWASHER, External Tooth, 3/8
17 930598 1 CAPSCREW, Hex Washer Head, Taptite, 3/8-16 x 1-1/2
18 1704419 1 STOP, Belt
19 1924940 1 WASHER, 3/8
20 1930598 3 CAPSCREW, Hex Washer Head, Taptite, 3/8-16 x 1-1/2
21 1713187 1 PULLEY & HUB ASSEMBLY
22 105337 1 KEY, HI PRO, 1/4 x 2.000
23 1720532 1 CLUTCH, Electric
24 1960370 1 CAPSCREW, Hex Head, 7/16-20 x 2-1/2
25 1918199 1 LOCKWASHER, Spring, 7/16
26 1708264 1 WASHER, Hex
27 172434 1 CLIP, Speed Wire
28 1720110 1 MANIFOLD, Exhaust
29 1936228 4 CAPSCREW, Hex Head, 5/16-18 x 3/4 G8
30 1919326 2 WASHER, 5/16
31 1676183 1 CLAMP, Exhaust
32 1931342 1 CARRIAGE BOLT, 5/16-18 x 2-3/4
33 1704357 1 DUCT, Muffler, Bottom
34 1960368 4 NUT, Speed, 1/4-20 Lug
35 1720109 1 MUFFLER
36 1935255 1 NUT, Speed, 5/16-18 LUG
37 1917356 6 LOCKWASHER, Spring, 5/16
38 1917372 1 NUT, Hex, 5/16-18
39 1921333 1 CAPSCREW, Hex Head, 5/16-18 x 1.000
40 1721202 1 BAFFLE, Muffler
41 1919326 2 WASHER, 5/16
42 1721987 1 DECAL, 18HP Brigga & Stratton INTEK
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
* Contact your Briggs & Stratton distributor for repair parts.
The above parts group applies to the following Mfg. Nos.:
1693583 Baron, 18HP Tractor
1693494 Baron, 18HP Tractor (Export)
1693686 Baron, 18HP Tractor (Export)
