Generac
®
Power Systems, Inc.
17
ITEM
PART NO.
QTY.
DESCRIPTION
1
0C8885
1
XFER SW-W 200A600V3P
2
0A9949
9
LUG SLDLSS 400-#4X1/4-20 CU7AL
3
0C4896
9
SCREW FHM M8-1.25 X 20MM CR
4
067989
9
NUT LOCK FL M8-1.25 YEL CHR
5
026902
7
SCREW HHTT #8-32 X 1/4 CZ
6
0C7907D
2
COVER LUG 3P 150/200AMP
7
045771
1
NUT HEX M8-1.25 G8 CLEAR ZINC
8
057329
1
LUG SLDLSS 350-#6X13/32 AL/CU
9
027482
1
WASHER SHAKEPROOF EXT 5/16 STL
10
022097
3
WASHER LOCK M6-1/4
11
0C8275
4
SCREW PPHM DSEMS M4-7 X 10 ZNC
12
073591
2
FUSE HOLDER
13
090388
5
SCREW HHTT M6-1.0 X 12 ZINC
14
0A1495
6
SCREW HHTT M4-0.7 X 10 BP
15
063617
1
RELAY PNL 12VDC DPDT 10A@240VA
16
047411
2
SCREW HHC M6-1.0 X 16 G8.8
17
0A1661
2
RIVET POP .156 X .675 AL
18
0C4449A
1
ASS'Y-NTRL BL150-200A
19
0E2865
1
WELDMENT,TRANSFER SWITCH BOX
20
0D3718
1
COVER, TRANSFER SWITCH BOX
21
0C8308
2
DECAL TERMINAL SHOCK HAZARD
22
0C2262
1
DECAL TERMINAL STRIP
23
0F6165
2
WASHER M6 NYLON
24
0F5569
1
DECAL,SWITCH RATING
25
064101
4
NUT LOCK FL 3/8-16
26
0E2866
1
SUBPLT 200A TS 3R
27
087680
1
NUT WING M6-1.0
28
063378
5
HOLDER CABLE TIE
29
064761
5
TIE WRAP UL 5.6 X .10 NATL
30
063321
1
HANDLE XFER SWITCH 1-400A
31
073590A
2
FUSE 5A X BUSS
32
0D3587
1
DECAL, FUSE REPLACEMENT
33
067210A
1
DECAL GROUND LUG
34
0A9457
1
DECAL NEUTRAL
35
0D4545
1
DECAL, MANUAL OPERATION
36*
0E4307
1
DECAL,TEST SEQUENCE 2P TS 3R
37
081221
1
DECAL-UL LIST HSB
38
0A2284
2
SCREW SWAGE 8-32 X 1/2 Z/YC
39
063306
1
3-PHASE POWER MONITR
40
066972
1
SOCKET RELAY OCTAL 8P 300V-10A
41**
0E4358
2
DECAL,LUG TORQUE INFO
42***
0F6521
1
DECAL TRANSFER SWITCH RTS
43
022129
1
WASHER LOCK M8-5/16
* CENTER DECAL ON INSIDE OF THE COVER (ITEM #20)
** INSTALL ACROSS E & N TERMINALS
***INSTALL ON FRONT OF THE COVER (ITEM #20)
Section 6 — Exploded Views and Parts List
Generac GTS “W” Type Transfer Switch
200 A, 3-pole Switch Assembly – Drawing No. 0E4312$-F
