LEGEND
GTS
NOTES:
1.) ALL CONTACTS SHOWN WITH
TRANSFER SWITCH IN UTILITY
POSITION.
B
A
WHITE
RED
LS2
LS3
LS1
T1 T2
2 3 5 6
1 4
C - CONTACTOR ACTUATING COIL
GTS - TRANSFER SWITCH CONTACTOR
LS1,LS2,LS3 - LIMIT SWITCHES, ACTUATOR
PM - POWER MONITOR, 3 PHASE UTILITY
TR - RELAY, TRANSFER
TS - TERMINAL STRIP (CUSTOMER CONNECTION)
3
4
5
N1B
N2A
N3
PM
N1B N1A
PM
F2
N2
N1
F1
N1B
N2A
126
F1,F2 - FUSE 5A SENSING
1 8
ADD JUMPER WIRE FROM PM
TERMINALS 1 TO 8.
2.) FOR SINGLE PHASE OPERATION,
12 Generac ® Power Systems, Inc.
Section 5 — Electrical Data
Generac GTS “W” Type Transfer Switch
200 Amp, 3-pole Switch – Drawing No. 0D3818-A
