20 306–646
TECHNICAL DATA
Air Operating Range
Bulldog Models 204–287, 215–873,
222–526, and 223–984 40–100 psi (3–7 bar) . . . . . . . . . .
King Models 222–248, 222–539,
and 223–991 40–90 psi (3–6 bar) . . . . . . . . . . . . . . . . . . . .
Air consumption
Bulldog Models 204–287, 215–873,
222–526, and 223–984 13 cfm per gallon pumped . . . . .
(0.10 m # /min/liter) at 100 psi (7 bar) air pressure;
up to 120 cfm (3.4 m # /min/liter) with pump
operated within recommended range
King Models 222–248, 222–539,
and 223–991 11 cfm per gallon pumped . . . . . . . . . . . . . . .
(0.31 m # /min/liter) at 70 psi (5 bar) air pressure;
up to 80 cfm (2.26 m # /min/liter) with pump
operated within recommended range
Pump Cycles Per Gallon (liter) 7 (26.5) . . . . . . . . . . . . . . . . . . .
Maximum Recommended
Pump Speed 60 cycles/min; . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.5 gpm (32 liter/min) delivery
Maximum Pump Discharge Pressure
Bulldog Models 204–287, 215–873,
222–526, and 223–984 1000 psi (70 bar) . . . . . . . . . . . . .
King Models 222–248, 222–539,
and 223–991 1800 psi (124 bar) . . . . . . . . . . . . . . . . . . . . .
Wetted Parts Carbon Steel, Zinc Plating, Nitralloy, Bronze, . .
Ultra–High Molecular Weight Polyethylene,
r , Delrin r , Viton r , Thiokol r
Weight 101 lb (46 kg) approximate . . . . . . . . . . . . . . . . . . . . . . .
Delrin r , r , and Viton r are registered trademarks of the
DuPont Co.
Thiokol r is a registered trademark of the Thiokol Chemical Corp.
THE GRACO WARRANTY AND DISCLAIMERS
WARRANTY
Graco warrants all equipment manufactured by it and bearing its name to be free from defects in material and work-
manship on the date of sale by an authorized Graco distributor to the original purchaser for use. As purchaser’s sole
remedy for breach of this warranty, Graco will, for a period of twelve months from the date of sale, repair or replace
any part of the equipment proven defective. This warranty applies only when the equipment is installed, operated and
maintained in accordance with Graco’s written recommendations.
This warranty does not cover, and Graco shall not be liable for, any malfunction, damage or wear caused by faulty
installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tam-
pering, or substitution of non–Graco component parts. Nor shall Graco be liable for malfunction, damage or wear
caused by the incompatibility with Graco equipment of structures, accessories, equipment or materials not supplied
by Graco, or the improper design, manufacture, installation, operation or maintenance of structures, accessories,
equipment or materials not supplied by Graco.
This warranty is conditioned upon the prepaid return of the equipment claimed to be defective to an authorized Graco
distributor for verification of the claim. If the claimed defect is verified, Graco will repair or replace free of charge any
defective parts. The equipment will be returned to the original purchaser transportation prepaid. If inspection of the
equipment does not disclose any defect in material or workmanship, repairs will be made at a reasonable charge,
which charges may include the costs of parts, labor and transportation.
DISCLAIMERS AND LIMITATIONS
THE TERMS OF THIS WARRANTY CONSTITUTE PURCHASER’S SOLE AND EXCLUSIVE REMEDY AND ARE IN LIEU OF ANY OTHER WAR-
RANTIES (EXPRESS OR IMPLIED), INCLUDING WARRANTY OF MERCHANTABILITY OR WARRANTY OF FITNESS FOR A PARTICULAR
PURPOSE, AND OF ANY NON–CONTRACTUAL LIABILITIES, INCLUDING PRODUCT LIABILITIES, BASED ON NEGLIGENCE OR STRICT
LIABILITY. EVERY FORM OF LIABILITY FOR DIRECT, SPECIAL OR CONSEQUENTIAL DAMAGES OR LOSS IS EXPRESSLY EXCLUDED
AND DENIED. IN NO CASE SHALL GRACO’S LIABILITY EXCEED THE AMOUNT OF THE PURCHASE PRICE. ANY ACTION FOR BREACH OF
WARRANTY MUST BE BROUGHT WITHIN TWO (2) YEARS OF THE DATE OF SALE.
EQUIPMENT NOT COVERED BY GRACO WARRANTY
GRACO MAKES NO WARRANTY, AND DISCLAIMS ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, WITH RESPECT TO ACCESSORIES, EQUIPMENT, MATERIALS, OR COMPONENTS SOLD BUT NOT MANUFACTURED BY
GRACO. These items sold, but not manufactured by Graco (such as electric motor, switches, hose, etc.) are subject to
the warranty, if any, of their manufacturer. Graco will provide purchaser with reasonable assistance in making any
claim for breach of these warranties.
IMPORTANT PHONE NUMBERS
TO PLACE AN ORDER, contact your Graco distributor,
or call this number to identify the distributor closest to
you: 1–800–328–0211 Toll Free
FOR TECHNICAL ASSISTANCE, service repair infor-
mation or assistance regarding the application of Graco
equipment: 1–800–543–0339 Toll Free
Factory Branches: Atlanta, Chicago, Dallas, Detroit, Los Angeles, West Caldwell (N.J.)
Subsidiary and Affiliate Companies: Canada; England; Switzerland; France; Germany; Hong Kong; Japan
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
PRINTED IN U.S.A. 306–646 12–58 Revised 10–90
