Graco BULLDOG 222248 - Manual (Page 11)

11 306–646
Fig 3
53
45
42
SEE DETAIL A
34
SEE DETAIL B
38
SEE DETAIL C
3
30
6
36
37
28
31
11
28
*27
29
7
21
41
8
TORQUE TO
60 ft–lb (82 N.m)
44
TORQUE TO
40–50 ft–lb
(54–68 N.m)
50
52
26
62
59
61 27*
60
DISPLACEMENT PUMP 222–638
REF. NO. 2
DISPLACEMENT
PUMP INCLUDES
ITEMS 3–38, 56–66
66
DETAIL C
LIPS OF
V–PACKINGS
MUST
FACE UP
11
REF
3
REF
*65
INTAKE
VALVE
GLAND/
PACKING
STACK
DETAIL B
LIPS OF
PACKING
MUST
FACE UP
*56
*35
38
REF
DETAIL A
21
REF
26
REF
LIPS OF
V–PACKINGS
MUST
FACE
DOWN
60
REF
64*
THROAT
GLAND/
PACKING
STACK
4
