Table 1-4 Jumper Settings in EXT Power Mode

Jumper

Default

Position

Setting

Description

2-3

Sets the board for 5V
operation

1-2

EXT

Sets the board to be
powered externally
through J1

1-2

P_IO_5V

Outputs 5V on pin 1 of
the I/O connector, J35.
This jumper should be
removed if you do not
want to output 5V on
this pin.

DEMO9S08AC60E User’s Guide, Rev. 0.1

Freescale Semiconductor

1.9.3 I/O Connector

The DEMO9S08AC60E can also be powered through pin 1 of the I/O connector
J35. To power the board in this manner the jumper on W2 should be removed
and positive 5V DC should be applied on pin 1 of J35. This voltage input is not
regulated on the board so care should be taken to provide a clean 5V signal.
LED D1 will light green to let you know that power has been correctly applied
to the board. Jumper settings are detailed below

Table 1-5 Jumper Settings in I/O Connector Power Mode
