haier HRE10WNAWW - Manual (Page 8)

1. Remove hinge cover screw.
2. Remove the top hinge cover.
3. Loosen the top hinge screws using a phillips head screwdriver.
4. Adjust the door or put a spacer in between and then tighten the
screws.
5. Replace the top hinge cover.
Door Alignment
(see fig. # 1)
Reversing the Door Swing
fig. # 1
English
7
Left/right door opening method:
This product provides the reversing of the left/right door opening. You
can select your preference of door opening by following the procedure
to make the change.
Dismantling: (see fig. # 1)
1. Fix refrigerator door by sticking adhesive tape on both sides to hold
door in place.
2. As shown in fig. 1, dismantle the hinge box cover on the upper part
of refrigerator door with a phillips head screwdriver. Then remove
the screws from the hinge. Take out the hinge by pulling it vertically,
and keep it in a safe place.
3. Remove the adhesive tape on refrigerator door, lift and take down
refrigerator door, and carefully put it aside.
