1. Introduction
BE-IR30 / 31 2
Thank you very much for your purchase of the Hitachi BE-IR30/31 Black and White Camera
Module.
Prior to using this camera , read this manual carefully.
2. General
The BE-IR30/31 is a monochrome camera module featuring sensitivity in the near infrared
spectrum using a 1/3-inch size CCD imaging device. Resolution is outstanding, while the very
small size provides optimum suitability for incorporation into equipment where space is limited.
Model coding
BE-IR3
Signal system N: EIA
P: CCIR
Optical system A: Without lens mount
B: With lens mount and board lens
C: With pinhole lens mount*
Synchronization 0: Internal sync
1: External sync
*Type C is mount only. Specify at time of order when requiring pinhole lens,
CS or C mount adapter
3. Composition
1) Black and white camera module 1
2) Interface cable 1
Note : The standard accessory cable is 300 mm signal conductor.
Different length cable requires shielding to avoid external noise.
4. Specifications
1) Imaging device 1/3 inch interline CCD
No. of pixels EIA : 811(H) 508(V)
CCIR : 795(H) 596(V)
No. of effective pixels EIA : 768(H) 494(V)
CCIR : 752(H) 582
Pixel pitch EIA : 6.35(H) 7.4(v)
µ
m
CCIR : 6.5(H) 6.25(V)
µ
m
