Page 7
07/05
ID# M671111
7
PARTS LIST - (See Hardware Identifier)
Item Qty. Part No.
Description
1
1
203470
Washer, Flat, 1.5” O.D.
2
1
806620
Base Assembly
3
1
804833
Exacta Height Assembly
4
1
908006
Top Pole Section
5
1
90810701
Middle Pole Section
6
1
908142
Bottom Pole Section
7
2
206934
Large Eyebolt, 3/8”
8
8
203063
Nylon Insert Lock Nut, 3/8-16
9
1
206634
Rod, 1/2 x 9-1/2 Long
10
1
203099
Nut, Ny-lock, 5/16-18
11
4
201681
Spacer, Plastic .530 I.D. x .88 Long
12
1
202662
Bolt, Hex Head, 5/16-18 x 4-1/2 Long
13
2
200341
Nut Cover
14
11*
203100
Hex Flange Nut 5/16-18
15
1
204832
Bracket, Pole Mount
16
2
203053
Carriage Bolt, 5/16-18 x 4 Long
17
4
203232
Washer, Metal, 3/4” O.D.
18
4*
201124
Lock Nut, 3/8-16
19
4
206360
Bolt, Hex Head, 3/8-16 x 2-5/8 Long
20
2
204858
Spacer, Plastic Biscuit
21
2
204857
Spacer, Metal 1/2” O.D. x 1.44 Long
22
2
204859
Cover, Pin Slide
23
1
203038
Carriage Bolt, 5/16-18 x 2-3/4 Long
24
1
204850
Pin, Locking
25
1
204853
Lanyard, Black Coil
26
4
201683
Spacer, .530 I.D. x 1.5 Long
Item Qty. Part No.
Description
27
2
908256
Bracket, Backboard Support
28
2
200874
Spacer, Steel .402 I.D. x .5 O.D. x 1.5 Long
29
6
206244
Bolt, Hex Head, 1/2-13 x 8 Long
30
4
201642
Spacer, Plastic, .530 I.D. x .625 Long
31
7
206340
Lock Nut, Hex Head, 1/2-13
32
2
904820
Elevator Tube, Lower - Long
33
2
204838
Spring, Counter Balance
34
1
Rim
35
2
904808
Elevator Tube, Upper - Short
36
2
201682
Spacer, .530 I.D. x 1.875
37
2
900867
Plate, Triangle, (Black)
38
1
207103
Cap, Pole Top
39
2*
200520
Screw, #8 x 1/2
40
1
202605
Bolt, Hex, 1/2-13 x 4.25 Long
41
1
206219
Plug, Tank Cap
42
1
206990
Reinforcement Bracket
43
1
204290
Net
44
4*
205528
Bolt, Hex Flange, 5/16-18 x 1 Long
45
6
203309
Washer, .406 I.D. x 1 O.D. Flat
46
1
511679
Label, Height Adjustment and Moving
47
4
204961
Bolt, Hex Head, 5/16-18 x .625 Long
48
1
900033
Bracket, Slam Jam
49
1
203796
Bolt, Tee, 3/8-16, 5” Long
50
1
200318
Bracket, Reinforcement, Slam Jam
51
1
203472
Spring, Rim
52
1
203795
Nut, Special, 3/8-16
NOTE: Hardware kit is designed for more than one style of basketball
system. Not all hardware will be used.
* YOU MAY HAVE EXTRA PARTS WITH THIS MODEL.
WARNING: IF YOUR SYSTEM IS EQUIPPED WITH AN ACRYLIC
BACKBOARD, EXAMINE BACKBOARD FOR ANY DAMAGE THAT MAY
HAVE OCCURRED DURING SHIPMENT. CRACKS IN THE BACKBOARD
COULD RESULT IN SUDDEN BREAKAGE. IF BACKBOARD IS DAMAGED
IN ANY WAY PRIOR TO OR AFTER ASSEMBLY, CALL TOLL-FREE
NUMBER:
U.S. 1-800-558-5234; CANADA: 1-800-284-8339; http://www.huffysports.com
