Item No. Description Part No. Qty Item Note
1 DECAL CAUTION 111-0083 1
2 GRIP FIX EXT 5/16 04020 2
3 BATTERY COVER 111-0595 1
4 BOLT HANDLEBAR 09785 2
5 CABLE ENGINE BRAKE V/S 111-0998 1
6 CABLE GUIDE 410037 4
7 CABLE_CLUTCH V/S 111-1083 1
8 CAP FOR M8 NUT BLACK HY234051 2
9 HANDLEBAR CLAMP PLATE 340028 2
10 FLAP_GRASSBAG 111-0196 1
11 DEFLECTOR 111-0633 1
12 ENGINE B&S INTEK EDGE 55 OHV 111-1000 1
13 ENGINE STOP LEVER 111-0102 1
14 FRAME_GRASSBAG 111-0194-03 1
15 GRASSBAG 111-0952 1
16 GUIDE_ROPE 305093 1
17 HANDLEBAR LOWER 410034W 2
18 HANDLEBAR UPPER MOULDED 341029 1
19 LEVER CLUTCH 306094W 1
20 BOLT COACH M8 x 40 GRADE 8.8 09379 2
21 NUT M6 NYLOC ‘T’ TYPE 09438 2
22 NUT M8 NYL INSERT T TYPE 09441 4
23 PIN PIVOT 340182 2
24 RATCHET PLATE HOC 111-0201 1
25 FASTENER DRIVE 6.5 341033 1
26 ROD DEFLECTOR 560017 1
27 SCREW TAPTITE M6*16 09365 4
28 FASTENER DRIVE 300144 4
29 SCREW TAPTITE UNC 3/8"*1 1/4" 09349 3
30 SCREW 06*20 PT PAN FLANGE 09687 2
31 SETSCREW M6x55 POSI PAN Z&N 09780 2
32 THROTTLE CONTROL TPYE T60 486031 1
33 SPRING DEFLECTOR 410030 1
34 CABLE VARIATOR 111-1193 1
35 KNOB M8 HANDWHEEL 480088 2
36 WASHER NYLON 19*11*1.6 09688 2
37 WASHER 5/16*7/8*15G GAVL 09267 4
38 BOLT COACH M8*25 GRADE 4.6 09373 2
39 PLUG TUBE 7/8*16G 300160 2
40 DECAL HAYTER ROYAL WARRANT 410087 1
41 DECAL SERIAL NUMBER -------- 1
42 DECAL ENGINE 486005 1
43 NUT M6 NYLOC P TYPE 09544 1
44 CABLE TIE HY3966 3
45 DECAL HEIGHT OF CUT 320006 1
46 GRASSBAG ASSEMBLY 111-0764 1 INCLUDES
1,10,14,15
47 BRACE HANDLEBAR 111-0739-03 2
48 WASHER PLAIN M6*12*1.6 09472 1
1.32
LIST PARTS MAINFRAME UPPER
