List of Holding Registers
Network Data Func.
Code
Name R/W Description
Reg. Range Res.
C044 PID deviation level
setting R/W Sets the allowable PID loop error
magnitude (absolute value), SP-PV,
range is 0.0 to 100%, resolution is
0.1%
1129h 0 to 1000 0.1 %
C052 PID FBV function high
limit R/W When the PV exceeds this value,
the PID loop turns OFF the PID
second stage output, range is 0.0 to
100%
112Eh 0 to 1000 0.1 %
C053 PID FBV function
variable low limit R/W When the PV goes below this value,
the PID loop turns ON the PID
second stage output, range is 0.0 to
100%
112Fh 0 to 1000 0.1 %
C070 Selection of OPE /
ModBus R/W Two option codes:
02 }OPE or option
03 }ModBus (485)
1137h 2, 3
C071 Communication speed
selection 1138h
C072 Node allocation 1139h
C074 Communication parity
selection 113Bh
C075 Communication stop bit
selection 113Ch
C076 Communication error
select 113Dh
C077 Communication error
time-out 113Eh
C078 Communication wait
time
NOTE: These network settings are
not accessible to ModBus. Use the
inverter keypad or digital operator
to edit. Refer to
“Network
Communication Settings” on page
3–60
.
113Fh
C081 O input span calibration R/W Scale factor between the external
frequency command on terminals
L–O (voltage input) and the
frequency output,
range is 0.0 to 200%
1141h 0 to 2000 0.1 %
C082 OI input span calibration R/W Scale factor between the external
frequency command on terminals
L–OI (voltage input) and the
frequency output,
range is 0.0 to 200%
1142h 0 to 2000 0.1 %
C086 AM offset calibration R/W Offset adjustment of AM output.
Range is 0.0 to 10.0
Adjust together with B080 (AM
gain adjustment)
1145h 0 to 100 0.1 V
C091 Debug mode enable Displays debug parameters.
Two option codes:
00
}Disable
01 }Enable
C101 Up/Down memory mode
selection Controls speed setpoint for the
inverter after power sycle.
Two option codes:
00
}Clear last frequency (return to
default frequency F001)
01 }Keep last frequency adjusted
by UP/DWN
1149h 0, 1
