LOCATION OF CONTROLS
14
• The S-Video connection is provided for high performance laser discs, VCR's, etc. that
have this feature. Use this connection in place of the standard video connection if your
device has this feature.
• If your device has only one audio output, connect it to the left audio jack on the TV.
• Refer to the operating guide of your other electronic equipment for additional
information on connecting your hook-up cables.
LOCATION OF CONTROLS
Details are described on the page shown by the number attached to the part name
(example: ).
Front view illustration
NOTE: The front and rear view shows the illustration for the 31DX22B Table Top. The
31KX41K console with VCR storage is not shown bu the controls and terminals are the
same.
Rear view illustration
FRONT PANEL JACKS AND CONNECTIONS
• The front panel jacks are provided as a convenience to allow you to easily connect a
camcorder or VCR as shown in the following examples.
Front panel connections illustration
NOTE:
• Completely insert the connection cord plugs when connecting to front panel jacks. If you
do not, the played back picture may be abnormal.
