Hayter Mowers SST38/ST42 - Manual (Page 23)

PARTS LIST - CUTTERDECK 1.23 1.23
ITEM NO. DESCRIPTION. PART NO. 38” PART NO. 42” QTY. ITEM NOTE.
150006PM0512010
1 Cover Belt 150029 151035 1
2 Spring MU165X118 MU165X118 1
3 Tensioner Primary 150043W 150043W 1
4 Lock Nut -1/2” UNF MU15X112 MU15X112 4
5 Pulley - Idler MU690024 MU690024 4
6 Cover - Input 150028 151036 1
7 Nut - Pulley MU15X121 MU15X121 3
8 Pulley - Drive Input MU1001423 MU1001423 1
9 Belt - Primary 151037 151037 1
10 Shoulder Washer T004446 T004446 1
11 Spring 150019 150019 1
12 Bracket - Tensioner 150010 150010 1
13 Pulley MU94592 MU94592 3
14 Belt - Secondary 150044 151038 1
15 Spacer - Pulley 150014 150014 2
16 Washer 09280 09280 1
17 Setscrew - 1/2” UNF x 1 1/4” 09155 09155 1
18 Pulley Spacer / Seal MU1001197 MU1001197 3
19 Nut MU15X79 Z MU15X79 Z 2
20 Stud - 1/4 Turn 150051 150051 2
21 Screw - Self Tapping MU25X6 MU25X6 15
22 Clip 150053 150053 4
23 Pulley Enclosure 150030 151028 1
24 Bracket 150054 150054 2
25 Washer MU17X165 MU17X165 3
26 Nut MU15X100 MU15X100 3
27 Nut MU15X84 MU15X84 4
28 Pop Rivet 3/16” Alu 09320 09320 8
29 Strip Retainer 150012 150012 1
30 Flap Deflector 150013 150013 1
31 Bolt - Coach MU2X53 MU2X53 2
32 Pin - Circle MU711764 MU711764 4
33 Washer MU17X91Z MU17X91Z 4
34 Wheel - Gauge MU92265 MU92265 4
35 Bolt - Shoulder MU94025 MU94025 4
36 Blade - Enclosure W/A 150020 151020 1
37 Front Skirt 150040 151022 1
38 Screw - Self Tapping 09533 09533 5
39 Bearing Housing MU1001390 MU1001390 3
40 Shaft - (Short) MU1001391 MU1001391 2
41 Shaft - (Long) MU1001389 MU1001389 1
42 Adaptor - CutterBlade MU92466 MU92466 3
43 Cutterblade - RH 150034 150034 1
44 Cutterblade - Centre 150033 150032 1
45 Cutterblade - LH 150032 150032 1
46 Washer - Belville MU17X166 MU17X166 3
47 Bearing Upper MU92281 MU92281 3
48 Bearing Lower MU92282 MU92282 3
49 Spacer MU1001197 MU1001197 3
50 Blade - Bearing Assembly Short MU1001393 MU1001393 2 (Includes 39,40,47,49,48,55)
51 Blade - Bearing Assembly Long MU1001392 MU1001392 1 (Includes 39,41,47,48,49,55)
52 Washer - Shim 150059 150059 1
53 Setscrew - Mid 09395 09395 1
54 Nut Mid - Nyloc 09447 09447 1
55 Grease Nipple MU690501 MU690501 3
56 Decal 40-13-010 40-13-010 2
57 Stud - 1/4 Turn 150052 150052 2
