Subwoofer Output
Remote IR Input
Remote IR Output
HDMI Output
USB 2 Po
rt
FM Antenna
AM Antenna
Subwoofer Trigger Output
Component Video Monitor Outputs
S-Video Monitor Output
Composite Video Monitor Output
Optical Digital Audio Input
TV Analog Audio Inputs
Auxiliar
y Analog
Audio Inputs
Analog Audio Outputs
Coaxial Digital Audio Output
Coaxial Digital Audio Input
Speaker Outputs
AC P
ower Input
NOTE:
To
make it easier to follow the instructions throughout the manual that refer to this illustration,
a copy of this page may be d
ownloaded from the Product Support section at
www
.har
mankardon.com.
REAR-PANEL CONNECTIONS
