10 — English

PRE-OPERATION

TRIGGER SAFETY LATCH

In the engaged position, the trigger safety latch
prevents the gun from being triggered accidentally.
Pull the latch up to engage it (See Figure 10). ALWAYS
engage the trigger safety latch when the unit is not in
use.

Figure 10 - Trigger lock

Trigger lock
(not engaged)

Trigger lock
(engaged)

Figure 9 - Insert spray tips into the placard

For models 9030PW and 1335PW: Insert spray tips
into rubber grommets on placard (See Figure 9).
