The main parts of your Double Oven
TOP OVEN TEMPERATURE
& GRILL SELECTION
CONTROL
MAIN OVEN
TEMPERATURE
& FUNCTION CONTROL
CLOCK & OVEN
TIMER
OVEN LIGHT
GRILL PAN, FOOD
SUPPORT & ANTI-
SPLASH TRAY
TOP OVEN
DOOR
OVEN LIGHT
INNER
DOOR
GLASS
OVEN SHELF
DOOR
SWITCH
RATING PLATE –
Record the Model No. and the Serial No.
on KEY CONTACTS, back page.
GRILL
SETTING
CONTROL
HIGH SPEED
GRILL ELEMENT
STAY CLEAN
LINER
OVEN FAN
STAY CLEAN
LINER
MEAT PAN &
ROASTING RACK
INNER DOOR GLASS
MAIN OVEN
DOOR
❍ ❍
❍
