Anchor size
W 1/4" W 5/16" W 3/8"
(6.3 mm) (8 mm) (9.5 mm)
Overall Length
10-15/64" 10-15/64" 6-19/64" 10-15/64"
(260 mm) (260 mm) (160 mm) (260 mm)
Code No. 302976 302975 303621 302974
Anchor size
W 1/4" W 5/16" W 3/8"
(6.3 mm) (8 mm) (9.5 mm)
Overall Length
10-15/64" 10-15/64" 6-19/64" 10-15/64"
(260 mm) (260 mm) (160 mm) (260 mm)
Code No. 302979 302978 303622 302977
Anchor setting adaptor
(for manual hammer)
the female screw>
Anchor size Code No.
W1/4"
971794
(6.3 mm)
W5/16"
971795
(8 mm)
W3/8"
971796
(9.5 mm)
W1/2"
971797
(12.7 mm)
W5/8"
971798
(15.9 mm)
the headless screw>
Anchor size Code No.
W1/4"
971799
(6.3 mm)
W5/16"
971800
(8 mm)
W3/8"
971801
(9.5 mm)
W1/2"
971802
(12.7 mm)
W5/8"
971803
(15.9 mm)
3. Large hole boring (Rotation + Striking)
Guide
Plate Center pin Core Bit Core bit Shank
(SDS-plus shank)
