76
Engine Oil Level Check Engine Oil Change
SERVICING YOUR OUTBOARD MOTOR
UPPER
LIMIT
LOWER
LIMIT
OIL FILLER CAP
OIL LEVEL DIPSTICK
SCREW
DRAIN PLUG COVER
DRAIN BOLT
Running the engine with a low oil
level can cause engine damage.
Check the engine oil level with the
engine stopped and the outboard
motor in the vertical position.
Unlock and remove the engine
cover (p.
).
Remove the dipstick and wipe it
clean.
Insert the dipstick all the way in,
then remove it and check the oil
level shown on the dipstick.
Remove the screw from the oil
drain cover, and remove the cover.
Install and lock the engine cover.
Install the oil filler cap and tighten
it securely.
If the oil level is low, remove the
oil filler cap, and add oil to reach
the upper limit mark shown on the
dipstick. Use the oil recommended
on p.
.
An engine oil evacuation device may
be used to remove the engine oil.
Drain the used oil while the engine is
warm. Warm oil drains quickly and
completely.
Unlock and remove the engine
cover (p.
).
1.
2.
3.
4.
5.
6.
1.
2.
74
78
74
