Hearth & Home Technologies • GFK4B Fan Kit • 4016-095 Rev H • 11/08 1
TM TM
Models:
GFK4B
Fan Kit
Installation
Instructions
If you need clarifi cation of any of the instructions contained here contact your dealer or the Technical Services Department
at 1-800-927-6841.
The GFK4B Fan Kit has been designed to circulate room air through the appliance to enhance heat output. The fan kit oper-
ates on 120VAC, 60 Hz power. This is available through a receptacle in the factory installed junction box. The junction box
is located in the controls compartment of the appliance.
A control module is provided with the fan kit which automatically turns the fan on and off at preset times and is equipped with
a variable speed control to provide a quiet forced air fl ow at the desired speeds.
Check Contents of Shipping Carton
Compare contents of carton in Table 1 with the actual parts received. If any parts are missing or damaged, contact your
dealer before starting installation. Do not install a damaged fan kit.
Installation Precautions
The GFK4B Fan Kit is tested and safe when installed in accordance with this installation manual. It is your responsibility to
read all instructions before starting installation and to follow these instructions carefully during installation to assure maxi-
mum benefi t from, and safe operation of, the fan.
Note: An arrow (¨) found in the text signifi es change in
content.
Sharp Edges
• Wear protective gloves and safety
glasses during installation.
CAUTION
Note: This appliance must be electrically wired and grounded
in accordance with local codes or, in the absence of local
codes, with National Electric Code ANSI/NFPA 70-latest
edition or the Canadian Electric Code CSA C22.1.
Shock Risk
Explosion Risk
Do NOT wire 110-120 VAC to gas control
valve.
Do NOT wire 110120 VAC to wall switch
• Incorrect wiring will damage millivolt
values.
• Incorrect wiring will override IPI safety
lockout and may cause explosion.
WARNING
Shock Risk
Fire Risk
Use ONLY optional accessories approved
for this appliance.
• Using non-listed accessories voids
warranty.
• Using non-listed accessories may result
in a safety hazard.
• Only Hearth & Home Technologies
approved accessories may be used
safely.
WARNING
Note: You may not need all parts included with this kit.
Table 1 Contents of Carton
Description Qty.
Fan 1
Screws 6
Foam Tape 2
Control Module 1
Electrical Cord 1
Magnetic Tape 2
Fan Bracket 1
Jumper Wire (blue) 1
¨
