- 24 -
LCD TV Service Manual
Hisense Confidential
2—Refer to the next page instruction to select the communicate port.
3—Press the icon beside the baud rate and make sure it is green as the below picture.
4—Set the flash baud rate to 115200 as the below picture.
5—Click the browse button to select the *.bin file that will be updated.
6—Click the “start” button to update software.
Select mode
of Flash chip
Communicate
port
Set Flash
Baud Rate
Select *.bin
file
Start upgrade
Information of upgrade
process
Choose the current
USB conversion Port
Later choose com5
