3
®
ENGLISH
Setting Up Your Air Purifi er
1. Remove your air purifi er from the box and take it out of the clear plastic protective bag.
2. Place your QuietFlo ® Air Purifi er on a fi rm, fl at fl oor.
3. Before turning the Air Purifi er ‘on,’ open the front grill.
• For Models 30090 & 37090: To release the front grill, place your fi ngers
behind the tabs and pull forward. (Refer to Figure 1.)
• For Models 30105: To release the front grill, press the buttons on the side
until the front grill slides easily over the buttons. (Refer to Figure 2.)
4. The HEPA Filter is already installed in the correct position, but you need to con-
fi rm that it is fully inserted. To remove, grasp the edge of the fi lter frame and pull
it forward. Notice the orientation of the fl aps and seal, which should be pressed
fi rmly into the fi lter opening.
5. The carbon pre-fi lter is mounted inside the front grill with “hook” tape. Confi rm
that it covers the grill vents. (Refer to Figure 3.)
6. Place the fi lter installation reminder sticker on the inside edge of the front grill.
Circle the month and write the year of installation for the pre-fi lter and HEPA Filter.
7. Replace the fi lter and front grill. Be sure that the bottom grill tabs are in position
fi rst, and then push the top of the grill forward until it is closed. The unit is now
ready for normal operation. NOTE: This unit will not operate unless the door is
placed in the correct position.
8. Plug the unit into a 120V electrical outlet.
AIR PURIFIER PARTS
; ; ; ; ; ; ; ;; ;
;
;; ;
;
;
;
;; ;; ;
;
;
;
;; ;
;
;
;
;; ;; ;
;
;; ;
;
;; ;
;
;; ;; ;
;
;
;
;
;
;; ;
;
;; ;; ;
;
;; ;; ;
;
;; ;; ;; ;
;
;; ;; ;
;
;
; ;
@ @ @ @ @ @ @ @@ @
@
@@ @
@
@
@
@@ @@ @
@
@
@
@@ @
@
@
@
@@ @@ @
@
@@ @
@
@@ @
@
@@ @@ @
@
@
@
@
@
@@ @
@
@@ @@ @
@
@@ @@ @
@
@@ @@ @@ @
@
@@ @@ @
@
@
@ @
QuietFlo
Filter Pre-Filter Filter Reset
0 1 2 3
Tabs for
opening the
front grill
HEPA Filter
Pre-Filter
Front
Grill
Figure 1 - Models 30090 & 37090
Figure 3
Hook Tape
Grill Vents
Figure 2 - Model 30105
QuietFlo
Filter Pre-Filter Filter Reset 0 1 2 3
HEPA Filter
Pre-Filter
Front
Grill
Buttons for
opening the
front grill
Hook Tape Tab
