Fan RPM Motor HP
Fan Motor Part
No.
Fan Blade Part
No.
Fan Guard
Part No.
1140.(H.Models) 1 .5 25316401 22900401 23105701
1140.(Var ..Speed) 0 .75 25317101 2292625 23105701
830.(L.Models) 1 .5 25316601 22929501 23105701
830.(X.Models) 1 25316301 22929501 23105701
540.(Q.Models) 0 .5 25316201 22929301 23105701
1030.(E.Models,.230V) 2 .2.kW 25316905 23105601
1030.(E.Models,.460V) 2 .2.kW 25317005 23105601
Contact.the.InterLink™.Customer.Service.Department.for.parts.to.specific.condenser.models.at.
800-686-7278,.interlinkparts@heatcraftrpd .com,.or.www .interlinkparts .com .
In-Warranty Return Material Procedure
Material.may.not.be.returned.except.by.permission.
of.authorized.factory.service.personnel.of.Heatcraft.
Refrigeration.Products.in.Stone.Mountain,.Georgia ..A.
“Return.Goods”.tag.will.be.sent.to.be.included.with.the.
returned.material ..Enter.the.required.information.on.the.
tag.in.order.to.expedite.handling.at.our.factories.and.
prompt.issuance.of.credits ...All.parts.shall.be.returned.
to.the.factory.designated.on.the.“Return.Goods”.tag,.
transportation.charges.prepaid ..
.
The.return.of.a.part.does.not.constitute.an.order.for.
replacement ..Therefore,.a.purchase.order.must.be.entered.
through.your.nearest.Heatcraft.Refrigeration.Products.
representative ...The.order.should.include.part.number,.
model.number.and.serial.number.of.the.unit.involved .
Following.our.careful.inspection.of.the.returned.part.and.if.
it.is.determined.that.the.failure.is.due.to.faulty.material.or.
workmanship,.credit.will.be.issued.on.customer's.purchase.
order .
Parts by InterLink™
When.writing.to.the.factory.for.service.or.replacement.
parts,.refer.to.the.model.number.and.serial.number.of.the.
unit.as.stamped.on.the.serial.plate.attached.to.the.unit ..
If.replacement.parts.are.required,.mention.the.date.of.
installation.of.the.unit.and.date.of.failure,.along.with.an.
explanation.of.the.malfunctions.and.a.description.of.the.
replacement.parts.required . .
Table 9. InterLink™ Condenser Parts List
