HONDA Outboard Motor BF5A - Manual (Page 77)

BF5A
BADS
13.8 in (350 mm)
LA SA
20.7 in (525 mm)
39.6 in (1,005 mm) 44.7 in (1,135 mm)
17.5 in (445 mm) 22.5 in (572 mm)
59.5 lbs (27.0 kg) 60.6 lbs (27.5 kg)
3.7 kW (5.0 HP)
4,500 5,000 rpm
4 stroke OHV 1 cylinder, water-cooled
7.7 cu-in (127 cm )
0.028 0.031 in (0.70 0.80 mm)
Recoil starter
Digital Ignition Control Module (ICM)
Trochoid pump pressure lubrication
API standard (GL 4/5)
SAE 90 outboard motor gear oil
0.1 US qt (0.1 )
0.58 US qt (0.55 )
Water cooling with thermostat
Underwater exhaust
BPR5ES (NGK)
W16EPR-U (DENSO)
Diaphragm type fuel pump
Automotive unleaded gasoline
(86 pump octane or higher)
3.2 US gal (12 )
Forward-Neutral-Reverse (dog type)
45° right and left
5 stages (5°,9°,13°,17°,21°)
3 stages adjustment (30°, 45° and 70°)
7-25/32 7-31/64 in (3-200 190 mm)
0.028 0.031 in
(0.70 0.80 mm)
1,550 100 rpm
0.10 0.04 mm
0.15 0.04 mm
No other adjustment is needed
See page 45
See shop
manual
See shop
manual
ULTRA LOW EMISSION
API standard (SG, SH, SJ, SL)
SAE 10W-30
Gear case:
Engine:
Engine:
Gear case: Exhaust:
Intake:
75
Specifications
TECHNICAL AND CONSUMER INFORMATION
Tuneup
MODEL
Description Code
Type
Overall length
Overall width
Overall height
Transom height
Weight
Rated power
Full throttle range
Engine type
Displacement
Spark plug gap
Starter system
Ignition system
Lubrication system
Specified oil
Oil capacity
CARB star label
Cooling system
Exhaust system
Fuel pump
Fuel
Tank capacity
Gear change
Steering angle
Transom angle
Tilt angle
Standard propeller
(No. of blades-
diameter
pitch)
Spark plug gap
Idle speed
Valve clearance
(cold)
Other specifications
Spark plug
Honda outboards are power rated in accordance with NMMA procedures and using the ICOMIA standard 28/23.
