3-90-70741R13_05/13
Service Parts
VF3000
Beginning Manufacturing Date: N/a
ending Manufacturing date: active
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
Stocked
at depot
IteM deSCrIPtIOn COMMentS Part nuMBer
Boiler Coil Plate 1-10-07006
Brick Set of 2 1-00-00780
Bushing, Steel Sleeve, 3/8 OD x 1/4 OAL Pkg of 5 3-50-00058-5 Y
Cleanout Rod 2-00-01036 Y
Cleanout Slide 2-00-00227B
Combustion Blower 75cfm - 22 in cord 3-21-07522 Y
Combustion blower restrictor plate Pkg of 2 2-00-01023-2
Cord, 22” 3-20-29523 Y
Coupling (for Oil Burner Option) 1-10-01204W
Din Rail End Clamp 3-31-01021
Din Rail, 8”, (for Mounting Controls 3-31-01020
Door Assembly (for Oil Burner Option) 1-10-01203A
Door Hinge Qty 4 req 2-00-07203D
Element Cover (For Back up) 1-10-01008S
Feeder Adapter Plate 2-00-00152B
Fiber Board, 2” Thick, (for Oil Burner Option) 3-44-01760
Gasket 1/2” Rope (ash pan door) 20 Ft 1-00-53500 Y
Gasket 1” w/adhesive - 2 ply (fi re door) 20 Ft 1-00-88250 Y
Gasket Glue, 32 oz 3-42-4583
Gasket, 3/8” Round HD 5 Ft 1-00-43375 Y
Gasket, Boiler Plate 3-10-24758
Hopper clip 2-00-01070S
Jacket Front 2-00-00244S
Jacket Side, Left 2-00-00245-1S
Jacket side, Right 2-00-00245-2S
Jacket Top 2-00-00243S
Nozzle cover (for Oil Burner Option) 2-00-01164B
Oil burner Optional 1-00-01050
Oil to coal on/off control assembly 1-10-01205A Y
Plug, 3/4” Square 3-10-00600
Power Cord, 8 Ft 3-20-29685 Y
Pressure Temp Gauge - Bottom Mount 3-10-78422 Y
Safety Relief Valve 3-10-77382 Y
Steel Water Plate 2-00-01076L
Thermostat-low voltage 3-20-12080 Y
Touch-up Paint, Aerosol 3-42-7737
VF3K Kit assembly 1-00-01002A
