Figure 8-3. Spot Welder Tongs And Tips
Flat
Flat
(89 mm)
(89 mm)
6-1/2” (165 mm)
3-1/2”
3-1/2”
Standard Flat
205 552 205 553
MO
Offset
205 557
Standard Flat
205 552 205 553
Standard
205 552 205 553
FF
205 564
FH
205 566
STANDARD
MO OFFSET
TT-6
TT-9
FF
FH
(190 mm)
7-1/2”
Standard
205 552 205 553
G-7
S-0550 / Ref
9-1/2”
(241 mm)
6” (152 mm) 205 551
12” (305 mm) 040 198
18” (457 mm) 040 199
6” (152 mm) 205 554
12” (305 mm) 205 555
18” (457 mm) 205 556
12” (305 mm) 205 558
18” (457 mm) 205 559
12” (305 mm) 205 560
18” (457 mm) 205 561
8” (203 mm) 205 563
5” (127 mm) 205 565
8” (203 mm) 205 562
