USEFUL INFO
80
USEFUL
INFORMA
TION
Features:
• New Easy-to-Use On-Screen Menu Control (3 Language)
• New AV Network System Control
Control up to 4 components with one remote
2 IR Mouse cables included
Control Codes Stored in AV Control Center
• Two Tuner Split Screen except RGB modes.
• Illuminated and Preprogrammed Remote Control
• Power Management: ON/OFF via signal detection
• Menu Control Keys accessible from AV Control Center
• Picture Enhancement
• Input Signal Identification
Video:
• 1280 x 768 Display Resolution (50”)
• 1024 x 1024 Display Resolution (42”)
• 852 x 1024 Display Resolution (32”)
• ALiS (Alternate Lighting of Surfaces Technology) (32”,42”)
• High-Contrast Pure-Color Glass Shield
• Wide Viewing Angle: More than 160˚
• 4 Color Temperature Presets: Black/White-5400K, Standard-
6500K, Medium-7500K, High-9300K.
• Multiple Screen Fill Modes (4:3 Standard/Expanded/Zoom1/
Zoom2/16:9 Standard/Zoom)
1
• 4MB 10-bit 3D Y/C Comb Filter
• Picture Modes (Day and Night)
• Computer Display: VGA, (SVGA, XGA, SXGA-scaled)
Inputs:
• Power Input . . . . . . . . . . . . .AC 120V, 60Hz
• Power Consumption
- Refer to rear panel at the back of the Plasma
Monitor and AVC Center
• Antenna input impedance . . . . . . . . .75 Ohm
• Channel coverage . . . . . . . . . . . . . . .181ch.
VHF-Band . . . . . . . . . . . . . . . . . . . . .2 ~ 13
UHF-Band . . . . . . . . . . . . . . . . . . . .14 ~ 69
CATV Mid Band . . . . . . . . . . . . . . .A-5 ~ A-1
. . . . . . . . . . . . . . . . . . . . . . . . . . .A-I
Super Band . . . . . . . . . . . . . . . . . . . . .J-W
Hyper Band . . . . . . . . . . . . . . .W+1 - W+28
Ultra Band . . . . . . . . . . . . . . .W+29 - W+84
• Video . . . . . . . . . . . . . . . .1.0Vp-p, 75 Ohm
• S-Video
Luminance (Y) . . . . . . . . . .1.0Vp-p, 75 Ohm
Chrominance (C) . . . . . .0.286Vp-p, 75 Ohm
• Component Video
Luminance (Y) . . . . . . . . . . . . . . .1.0Vp-p, 75 Ohm
Chrominance (PB/PR) . . . . . . . . .0.7Vp-p, 75 Ohm
• Audio input Impedance . . . . . . . . . .47k Ohm
• Average input level . . . . . . . . . . . . . . . .470mVrms
• RGB . . . . . . . . . . . . . . . . . . . . . .0.7Vp-p, 75 Ohm
Outputs:
• Video . . . . . . . . . . . . . . . . . . . . .1.0Vp-p. 75 Ohm
• Audio . . . . . . . . . . . . . . . . . . .470mVrms, 1k Ohm
Audio:
• MTS Stereo/SAP
• TruBass and Matrix Surround
• 10W+10W (42HDT50/50HDT50)
• 7W+ 7W (32HDT50)
• Soft Mute (50% and 100%)
Supplied Accessories:
• Illuminated Preprogrammed Remote Control
• Batteries
• 9’ Monitor Connection Cable
• 6’ AC Cable (2)
• Subwoofer Cable
• IR Mouse Cable
• Speaker Accessories (42”/50”)
Optional Accessories:
• 42” stand, 32” stand
• Wall Mount Bracket
INPUTS/OUTPUTS
• Inputs: ............................................RGB, VIDEO 1-5
• Wideband Component Y, Pb,Pr ............................................2
• RGB: Analog Input ................................................................1
• Composite Video...................................................................4
• S-Video .................................................................................3
• Antenna (RF) Inputs..............................................................2
• Converter Box Output ...........................................................1
• Audio Output .........................................................................1
• Monitor Output ......................................................................1
• Headphone Output................................................................1
• Subwoofer Output .................................................................1
• DVI-HDTV .............................................................................1
SPECIFICATIONS
• Multi-Scanning: ................24-109kHz (h), 50-85Hz (v)
• Pixel Pitch(50HDT50) .....0.86(horiz.) x 0.81(vert.) mm
• Pixel Pitch(42HDT50) .....0.90(horiz.) x 0.51(vert.) mm
• Pixel Pitch(32HDT50) .....0.84(horiz.) x 0.39(vert.) mm
• FCC class: .................................B for Consumer Use
• Power Requirements: ........................108-132V, 60Hz
DIMENSIONS
Monitor without stand and speakers (42” and 50”)
32” 42” 50”
• Width 38 7/16” 40 9/16” 48
• Height 19 3/16” 25 1/16” 28 1/8
• Depth 3 3/4” 3 3/4” 4 1/8
• Weight 58 lbs. 86 lbs. 108 lbs.
Audio Video Control Center
• Width .........................................................16 15/16”
• Height ..............................................................3 3/8”
• Depth...............................................................9 1/2”
• Weight ..............................................................9 lbs.
1 Screen mode availability varies by input format
HDTV Monitors display HDTV when combined with an HDTV Tuner and Source.
All specifications, weights, and dimensions are subject to change without prior
notice. Please access www.hitachi.com/tv for detailed specifications and dimen-
sions for custom installations.
UltraVision Digital is a registered trademark of Hitachi Home Electronics (America),
Inc.
TruBass and the SRS
® symbol are trademarks of SRS Labs, Inc. TruBass
technology is incorporated under license from SRS Labs, Inc.
