Ports and Cables
Refer to the table below to find out which projector port and cable to use for connecting a
given device. Use this table for determining which cables to prepare.
About Plug-and-Play Capability
• This projector is compatible with VESA DDC 1/2B. Plug-and-Play can be achieved by
connecting this projector to computers that are VESA DDC (display data channel)
compatible. Please take advantage of this function by connecting the accessory RGB
cable to the RGB IN port (DDC 1/2B compatible). Plug-and-Play may not work
properly if any other type of connection is attempted.
• Plug-and-Play is a system composed of the computer, its operating system and
peripheral equipment (i.e. display devices).
• Please use the standard drivers as this projector is a Plug-and-Play monitor.
NOTE
Function Projector Port Connection Cables
RGB input RGB IN
Accessory RGB cable or optional RGB
cable with D-sub 15-pin shrink jack and
inch thread screws
AUDIO input
(from the computer)
AUDIO IN Optional audio cable with stereo mini jack
RS-232C communication CONTROL Optional RS-232C cable
S-video input S-VIDEO IN
Optional S-video cable with mini DIN 4-pin
jack
Video input VIDEO IN Accessory audio/video cable
Component video input
COMPONENT VIDEO Y
Optional component video cable COMPONENT VIDEO C
B
/P
B
COMPONENT VIDEO C
R
/P
R
Audio input
(from video equipment)
AUDIO IN L
Accessory audio/video cable or optional
audio cable with RCA jack
AUDIO IN R
